Yuken Type DSG Solenoid Valve | DSG-01-3C2-D24 | DSG-01-2B3B-A220 | NG6 NG10 | 51T Series

DSG Series High-Performance Solenoid Directional Valves

Product Overview: The DSG series solenoid operated directional valves are the cornerstone of hydraulic control systems across various industrial sectors. Featuring high-power wet-pin solenoids, the armature operates within the oil, eliminating external leakage at the pushrod while providing silenced switching and an extended service life through fluid damping. Whether utilizing the compact DSG-01 (NG6) or the high-flow DSG-03 (NG10), these valves deliver exceptional stability under operating pressures up to 31.5 MPa.

Featured models: DSG-01-2B3B-A220-51T, DSG-01-3C2-D24-N1-51T, and 0910 related specifications.

Key Technical Advantages:

• High Pressure & Flow Capacity: Precision-engineered internal galleries minimize pressure drop, allowing DSG-01 to handle up to 63 L/min and DSG-03 up to 120 L/min.

• Wet-Pin Solenoid Architecture: Provides superior heat dissipation and shock resistance, ensuring precision even after millions of high-frequency cycles.

• 51T High-Reliability Design: The 51T design series optimizes the seal structure and armature fit, enhancing operational reliability in harsh industrial environments.

• Versatile Electrical Interfaces: Supports standard terminal boxes (N1) or plug-in connectors, compatible with global power standards like A220 (AC 220V) and D24 (DC 24V).

Detailed Specifications & Parameters:

• Featured Model Matrix:

  • DSG-01-2B3B-A220-51T: Size 6, 2-pos B3B function, AC 220V, Design 51T.

  • DSG-01-3C2-D24-N1-51T: Size 6, 3-pos 3C2 function (Closed Center), DC 24V, with Terminal Box.

  • DSG-03 Series: Nominal Size 10 for high-flow applications and larger actuators.

• Core Technical Specs:

  • Nominal Size: NG6 (Size 01) / NG10 (Size 03).

  • Max Operating Pressure: 31.5 MPa (315 bar).

  • Max Back Pressure: Up to 16-21 MPa (depending on model).

  • Voltage Ratings: AC 220V / DC 24V.

  • Enclosure Rating: IP65.
