Yuken Type DSG-01 & DSG-03 Series High-Performance Solenoid Directional Control Valves

Product Overview: The DSG Series is a benchmark in the field of hydraulic directional control, renowned for its exceptional switching reliability, superior pressure resistance, and ultra-low operational noise. Fully compliant with ISO 4401 mounting standards, this series covers the direct-acting Size 01 (NG6) and Size 03 (NG10) footprints. With a fluid-dynamically optimized 3-chamber body design, the DSG series significantly reduces pressure drop even under high-flow conditions.

This category highlights essential high-performance configurations: the DSG-03-3C6 with AC220V coils, the DSG-01-2B2-D24-N1-51t equipped with manual override and D24 power, and the DSG-01-2B3B-D24-50 series. These valves are the premier choice for automated machine tools, light industrial machinery, packaging systems, injection molding, and general hydraulic power units (HPUs).

Key Technical Advantages:

• Wet-Pin Solenoid Design: The armature operates fully immersed in hydraulic oil, ensuring superior heat dissipation and lubrication. This results in quiet switching and a significantly prolonged mechanical life.

• Extreme Pressure Durability: Constructed with high-strength castings, the series is rated for pressures up to 31.5 MPa (4,500 PSI), effortlessly meeting the demands of high-pressure industrial circuits.

• Optimized Spool Engineering: Available in 3C6, 2B2, 2B3B, and other spool functions, ensuring smooth transitions, rapid response, and minimal hydraulic shock.

• Versatile Electrical Compatibility: Compatible with D24 (DC 24V), A220 (AC 220V), and other global voltage standards, with options like N1 (Manual Override).

Detailed Specifications & Parameters:

• Core Series: Yuken Type DSG Solenoid Valve.

• Featured Model Matrix: DSG-03-3C6-A220, DSG-01-2B2-D24-N1-51t, DSG-01-2B3B-D24-50, DSG-03-2B2.

• Core Performance Specs:

  • Nominal Sizes: Size 01 (NG6 / CETOP 03) and Size 03 (NG10 / CETOP 05).

  • Max Operating Pressure: Rated up to 31.5 MPa (315 Bar).

  • Max Flow Capacity: Up to 100 L/min for Size 01; up to 120 L/min for Size 03.

  • Voltage Specs: D24 (DC 24V) / A220 (AC 220V / 240V).

  • Design Sequence: 50 / 51 series industrial standards.
