Yuken Type DSG Series Solenoid Directional Control Valves

Product Overview: The DSG Series is a benchmark for high-efficiency directional control in the industrial hydraulic sector. Utilizing a wet-pin solenoid design, this series ensures smooth spool shifting, which significantly reduces operational noise while enhancing the heat dissipation of the coils through oil circulation. Fully compliant with ISO 4401 international standards, it covers both the direct-acting Size 01 (NG6) and the high-flow Size 03 (NG10) footprints.

This category features essential configurations: the DSG-01-3C4-D24 with DC power, the DSG-02-3C6-A220-DL equipped with a waterproof junction box, and the heavy-duty DSG-03-3C2-A-240-N-50. These valves are the premier choice for CNC machine tools, automated production lines, injection molding machines, and industrial hydraulic power units (HPUs).

Key Technical Advantages:

• High Pressure & Flow Capacity: Precision-cast for heavy-duty use, the DSG-01/02 series is rated for pressures up to 31.5 MPa, while the DSG-03 handles flow rates up to 120 L/min.

• Wet-Pin Solenoid Engineering: The armature operates fully immersed in hydraulic oil, ensuring superior lubrication and cushioning mechanical impact for an extended operational life.

• Modular Electrical Connectivity (DL/N): Supports multiple wiring formats, including DL (Waterproof Junction Box) and N (Plug-in type), featuring protection ratings up to IP65.

• Global Voltage Compatibility: Supports D24 (DC 24V), A220 (AC 220V), and A240 (AC 240V) power supplies to meet international electrical standards.

Detailed Specifications & Parameters:

• Core Series: Yuken Type DSG Solenoid Directional Valve.

• Featured Model Matrix: DSG-01-3C4-D24, DSG-02-3C6-A220-DL, DSG-03-3C2-A-240-N-50.

• Core Performance Specs:

  • Nominal Sizes: Size 01 (NG6), Size 02 (High-pressure NG6), Size 03 (NG10).

  • Max Operating Pressure: Rated up to 31.5 MPa (4,500 PSI).

  • Spool Functions: 3C4 (Closed center), 3C6 (P to T center), 3C2 (All ports blocked).

  • Design Sequence: Version 50 / 70 industrial engineering standards.
