Yuken Type DSG Valve | DSG-01 DSG-02 DSG-03 | Solenoid Directional Valve | D24 A220 A240

Yuken Type DSG Series Solenoid Directional Control Valves

Product Overview: The DSG Series is one of the most widely utilized high-performance solenoid directional valves in hydraulic control systems. Renowned for its superior flow-path design and wet-pin solenoid technology, this series maintains exceptional stability under high-pressure environments while minimizing pressure drop. Fully compliant with ISO 4401 international mounting standards, it covers Size 01 (NG6), Size 02 (NG6 High-pressure), and Size 03 (NG10) footprints.

This category features essential configurations: the DSG-01-3C4-D24 with 24V DC power, the DSG-02-3C6-A220-DL equipped with a waterproof junction box (DL), and the DSG-03-3C2-A240-N-50 built to the 50-series design sequence. These valves are the premier choice for CNC machine tools, automated production lines, hydraulic power units (HPUs), and injection molding machinery.

Key Technical Advantages:

• Wet-Pin Solenoid Technology: The armature operates fully immersed in hydraulic oil, ensuring smooth transitions, reduced mechanical noise, and superior heat dissipation for an extended coil life.

• Extreme Pressure & Flow Capacity: Precision-cast for heavy-duty use, the DSG-01/02 is rated for pressures up to 31.5 MPa, while the DSG-03 handles flow rates up to 120 L/min.

• Modular Electrical Connectivity (DL/N): Supports multiple wiring formats, including DL (Waterproof Junction Box) and N (Plug-in type), featuring protection ratings up to IP65 for harsh environments.

• Global Voltage Compatibility: Supports D24 (DC 24V), A220 (AC 220V), and A240 (AC 240V) power supplies, meeting international industrial electrical standards.

Detailed Specifications & Parameters:

• Core Series: Yuken Type DSG Solenoid Directional Valve.

• Featured Model Matrix: DSG-01-3C4-D24, DSG-02-3C6-A220-DL, DSG-03-3C2-A240-N-50.

• Core Performance Specs:

  • Nominal Sizes: Size 01 (NG6 / CETOP 3), Size 02 (High-pressure NG6), Size 03 (NG10 / CETOP 5).

  • Max Operating Pressure: Rated up to 31.5 MPa (4,500 PSI).

  • Spool Functions: 3C4 (Closed center), 3C6 (P to T center), 3C2 (All ports blocked).

  • Voltage Specs: DC 24V, AC 220V, AC 240V (50/60Hz).

  • Design Sequence: Version 50 industrial engineering standard.
