Yuken Type DSG Solenoid Valve | DSG-01-2B8 | DSG-03-3C2 | DSG-03-3C40-D24-50 | DC24V AC220V
| Model Number | DSG, DSG-03-3C40-D24-50, DSG-01-2B8-D24-N1-50, DSG-03-3C60-DL-D24 |
|---|
Product Description
Yuken Type DSG-01 & DSG-03 Directional Solenoid Valves
Product Overview: The DSG series represents the benchmark for reliability in industrial directional control valves. Engineered with high-performance solenoids, this series achieves exceptional switching frequencies and an extra-long service life. Whether utilizing the compact DSG-01 (NG6) or the high-power DSG-03 (NG10), the wet-pin solenoid architecture ensures smooth and quiet operation. Supporting both DC 24V for mobile systems and AC 220V for industrial machinery, the DSG series provides ultimate flexibility for complex hydraulic logic requirements.
Featured models include: DSG-03-3C40-D24-50, DSG-01-2B8-D24-N1-50, DSG-03-3C60-DL-D24, and DSG-03-3C2-A220-N1-50.
Key Technical Advantages:
High Pressure & Flow Capacity: The DSG-03 size handles operating pressures up to 31.5 MPa and flow rates up to 120 L/min, providing robust power for heavy-duty machinery.
Wet-Pin Solenoid Design: The armature is immersed in oil, drastically reducing friction and enhancing heat dissipation, preventing coil burnout during high-frequency cycles.
Versatile Electrical Interfaces: Available in terminal box (N1), plug-in, and indicator light (DL) configurations, simplifying field wiring and diagnostics.
Superior Shock Resistance: Optimized for mobile machinery and construction equipment, ensuring precise and reliable switching even under severe physical impact.
Detailed Specifications & Parameters:
Featured Model Matrix:
DSG-03-3C40-D24-50: Size 10, 3-pos 4-way (C40 Open Center), DC 24V, Design 50.
DSG-01-2B8-D24-N1-50: Size 6, 2-pos 4-way, DC 24V, equipped with Terminal Box N1.
DSG-03-3C60-DL-D24: Size 10, 3-pos 4-way (C60 Tandem Center), with Indicator Light DL.
DSG-03-3C2-A220-N1-50: Size 10, C2 Closed Center spool, AC 220V industrial supply.
Core Technical Specs:
Mounting Interface: ISO 4401-AB-03-4-A (NG6) / ISO 4401-AC-05-4-A (NG10).
Max Operating Pressure: 31.5 MPa (4568 PSI).
Rated Flow Rate: Up to 63 L/min (DSG-01) / 120 L/min (DSG-03).
Enclosure Rating: IP65.
