Vickers Type V Series High-Performance Industrial Single & Double Vane Pumps

Product Overview: The Vickers Type V Series fixed displacement vane pump is the global benchmark for reliability in industrial hydraulic systems. Engineered for extended service life and ultra-quiet operation, it is the preferred power source for stationary machinery worldwide. This range highlights premium specifications: 25V-17A-1C-22R, 25V14A-1C22R, and 35V30A-1A22R. Powered by patented Intra-vane technology, the V Series counterbalances radial hydraulic loads on the rotor, delivering exceptional efficiency and smooth flow output at continuous pressures up to 17.2 MPa (2500 PSI).

Key Technical Advantages:

• Patented Intra-vane Technology: This unique design balances the vane tip loading against the stator, significantly reducing friction and heat—ensuring thousands of hours of stable life under 2500 PSI loads.

• Ultimate Quiet Operation: Featuring an optimized 12-vane structure and precision-ground stator curves, operational decibels are kept far lower than comparable gear pumps—ideal for indoor factory environments.

• Modular Cartridge Maintenance: The internal pump core is a “drop-in” unit. Maintenance is streamlined—swap the internal cartridge to restore OEM-level performance without disconnecting heavy plumbing or housing.

• Cost-Efficient Power: Offers a superior balance of performance and procurement cost compared to high-pressure piston pumps, with significantly lower long-term maintenance requirements.

• Target Applications: Plastic injection machines, brick presses, hydraulic shears, automated assembly lines, and industrial Hydraulic Power Units (HPU).

Detailed Models & Parameters:

• Core Series: Vickers Type V Series (20V, 25V, 35V, 45V).

• Model Keywords: 25V-17A, 25V14A, 35V30A, 45V, 20V.

• Flow Ratings (USgpm @ 1200rpm):

  • 25V Series: 14 GPM (Approx. 45 cm³/rev), 17 GPM (Approx. 55 cm³/rev).

  • 35V Series: 30 GPM (Approx. 97 cm³/rev).

• Technical Specs Decoding:

  • 1: Shaft type (Standard straight keyed).

  • A / C: Porting orientation (A-In line, C-90° opposite).

  • 22: Design sequence identifier.

  • R: Rotation (Right-hand/Clockwise).

• Max Pressure Rating: Continuous operating pressure up to 17.2 MPa (2500 PSI / 172 Bar).
