Vickers Type V & VQ Series High-Performance Intra-Vane Double Pumps

Product Overview: The Vickers V and VQ Series Double Pumps are the definitive power source for heavy-duty hydraulic systems worldwide. Utilizing advanced Intra-Vane technology, this series integrates two independent displacement cartridges onto a single drive shaft, enabling exceptionally flexible power distribution. This selection features core high-performance models: 4535VQ, 4525VQ, 4520VQ, 3525VQ, and precision specifications 2520V12-A5-1AA-20-282 and 2520VQ-21-A-12-1-CC-20-R. With its unique intra-vane structure, this series maintains superior durability and low-noise performance even at pressures up to 21.0 MPa (3050 PSI), making it the ideal choice for injection molding and mobile machinery.

Key Technical Advantages:

• Patented Intra-Vane Efficiency: This design significantly reduces the vane-tip loading against the stator, minimizing friction and ensuring a long mechanical service life even under continuous high-pressure and high-speed cycles.

• Dual-Circuit Synergy (High-Low Control): The double pump architecture allows the system to adjust based on load: combining flows for rapid movement or isolating a single pump for pressure holding, significantly optimizing energy efficiency and reducing heat generation.

• Rapid “Drop-in” Cartridge Maintenance: Internal components are housed in self-contained cartridges. Maintenance is streamlined—swap the internal cores on-site in minutes without disconnecting heavy plumbing from the machine.

• Optimized for Industry & Mobile Use: The V Series is acoustically optimized for factory automation, while the VQ Series is ruggedized for the shock resistance and high-speed demands of construction machinery.

• Target Applications: Injection molding machines, die-casting equipment, CNC shears, material handling, refuse trucks, and heavy-duty industrial Hydraulic Power Units (HPU).

Detailed Models & Parameters:

• Core Series: Vickers Type V & VQ Series Double Pump.

• Model Keywords: 4535VQ, 4525VQ, 4520VQ, 3525VQ, 2520V12, 2520VQ21.

• Technical Specs Decoding:

  • A5 / A12 / A21: Displacement codes (based on USgpm @ 1200rpm).

  • 1AA / 1CC: Identifiers for shaft configurations (Keyed/Splined) and porting orientations.

  • 20 / 282: Official design sequence numbers representing internal structure and specialized specifications.

  • R: Denotes Right-hand (Clockwise) rotation direction.

• Performance Metrics:

  • Pressure Rating: Rated for continuous operation up to 17.2 – 21.0 MPa (2500 – 3050 PSI).

  • Speed Capability: VQ series supports high-speed operation up to 2200 – 2700 RPM.
