CG5V Series Pilot Operated Proportional Directional Valves

Product Overview: The CG5V series represents high-performance pilot-operated proportional valves designed to deliver precision speed and directional control for high-flow hydraulic systems. This series combines the flexibility of proportional solenoids with the robust driving force of a pilot-operated architecture, ensuring exceptional linearity and dynamic response even under high-pressure, high-flow conditions. Its rugged construction is built for harsh industrial environments, making it a staple in large presses, metallurgical machinery, and high-precision injection molding systems.

Featured models include: CG5V-8FW-D-M-U-D6-11, CG5V-8GW-D-MU-H7-11, CG5V-6FW-D-M-U-H5-20, and CG5V-8FW-D-M-U-D5-20.

Key Technical Advantages:

• Pilot-Operated Architecture: Compared to direct-acting valves, the pilot-operated design offers superior stability and spool switching force when managing high flow rates, effectively resisting flow force disturbances.

• High-Precision Proportional Control: Utilizes precision proportional solenoids to support continuous, stepless adjustment of flow and direction via electronic amplifiers.

• Flexible Electrical Interfaces: Offers multiple connectivity options (e.g., D5, D6, H7), compatible with mainstream industrial control buses and analog feedback systems.

• Low Hysteresis & High Repeatability: Optimized internal flow paths and feedback mechanisms ensure minimal hysteresis, meeting the strict consistency requirements of closed-loop control systems.

Detailed Specifications & Parameters:

• Featured Model Matrix:

  • CG5V-8FW-D-M-U-D6-11: Size 8, FW flow rating, D6 connection, Design series 11.

  • CG5V-8GW-D-MU-H7-11: Size 8, GW enhanced flow capacity, H7 advanced electrical interface.

  • CG5V-6FW-D-M-U-H5-20: Size 6 specification, H5 connectivity, 20 series enhanced performance.

  • CG5V-8FW-D-M-U-D5-20: Size 8, D5 standard interface, optimized for 24V proportional systems.

• Core Technical Specs:

  • Mounting Interface: Compliant with ISO 4401-05 (Size 6) / ISO 4401-08 (Size 8) standards.

  • Max Operating Pressure: Rated up to 315 – 350 bar.

  • Flow Control Capacity: Supports from 80 L/min (Size 6) to 300+ L/min (Size 8) depending on the model.

  • Command Signal: Optimized for standard proportional amplifier command inputs.
