Vickers Type 4535V Series High-Pressure Industrial Double Vane Pumps

Product Overview: The Vickers Type 4535V Series double fixed displacement vane pump is a definitive power solution for heavy industrial hydraulic systems. Integrating the 45V (Shaft End) and 35V (Cover End) cartridges onto a single drive shaft, this series provides independent dual-circuit supply—perfect for systems requiring high-low flow splitting or combined high-flow output. Featured models include: 4535V60A38-86DD20-22R, 4535V60-A38-86AA-22, 4535V60A38 1C022R, and 4535V60A25-86DD22R. Engineered with patented Intra-vane technology, the 4535V series reduces contact stress on the stator, ensuring ultra-quiet performance and extended service life at pressures up to 17.5 MPa (2500 PSI).

Key Technical Advantages:

• High-Flow Dual Output: The primary end delivers up to 60 GPM, while the secondary end supports 25/38 GPM, making it ideal for rapid cycle times and high-pressure holding phases.

• Patented Intra-vane Technology: The unique vane-within-a-vane structure balances tip loading, significantly extending stator life and minimizing operational decibels under heavy loads.

• Modular Cartridge Maintenance: Internal cartridges feature a “drop-in” design. Maintenance is streamlined—swap the internal core on-site to restore factory performance without disconnecting heavy plumbing.

• Robust Load Adaptation: The heavy-duty cast iron housing is built to withstand rigorous industrial shocks, ensuring long-term system stability.

• Target Applications: Large injection molding machines, rubber presses, ceramic brick presses, scrap metal shears, and industrial Hydraulic Power Units (HPU).

Detailed Models & Parameters:

• Core Series: Vickers Type 4535V Series (Double Vane Pump).

• Model Keywords: 4535V60A38-86DD20-22R, 4535V60-A38-86AA-22, 4535V60A38-1C022R, 4535V60A25-86DD22R.

• Flow Ratings (USgpm @ 1200rpm):

  • Shaft End (Pump 1 – 45V): 60 GPM (Approx. 193 cm³/rev).

  • Cover End (Pump 2 – 35V): 25 GPM (Approx. 81 cm³/rev) or 38 GPM (Approx. 121 cm³/rev).

• Technical Specs Decoding:

  • 86 / 1: Shaft configuration (e.g., standard keyed or heavy-duty shaft).

  • AA / DD: Port orientation codes (A-In line, D-180° opposite).

  • 22: Design sequence identifier.

  • R: Rotation (Right-hand/Clockwise).

• Max Operating Pressure: Rated continuous pressure up to 17.5 MPa (2500 PSI / 175 Bar).
