Vickers SV1-10 & SV1-06 Servo Valve | SV1-10/48/315/6 | SV1-10/16/120 | SV1-06/05/210

Vickers Type SV1 Series High-Performance Direct Drive Servo Valves

Product Overview: The Vickers SV1 Series represents the pinnacle of electro-hydraulic control, engineered for closed-loop systems requiring extreme dynamic response and precise flow regulation. As a Direct Drive servo valve, this series eliminates the complexity of a pilot stage, with powerful proportional solenoids actuating the spool directly. This results in ultra-fast frequency response and minimal hysteresis. Whether in press synchronization, injection molding precision, or aerospace test rigs, the SV1 series delivers exceptional linear output at pressures up to 315 Bar.

This page features a comprehensive model matrix ranging from the micro-flow Size 06 (5 L/min) to the high-power Size 10 (48 L/min), including core models like the SV1-10/48/315/6.

Key Technical Advantages:

• Ultimate Dynamic Response: The direct-drive design significantly reduces phase lag, allowing the system to maintain precise tracking under high-frequency step signals.

• Full Range of Sizes: Available in NG6 (Size 06) and NG10 (Size 10) specifications to match various power requirements.

• Superior Linearity & Resolution: Precision-ground spool and sleeve assemblies ensure minimal deadband and a smooth transition through the neutral position.

• High Reliability Construction: Features excellent contamination resistance and null stability, ensuring a long service life in continuous 24/7 production environments.

Detailed Specifications & Parameters:

• Core Series: Vickers SV1 Series Direct Drive.

• Featured Model Matrix:

  • SV1-06/05/210/5 (Size 06, 5 L/min, 210 Bar)

  • SV1-10/8/100/6 (Size 10, 8 L/min, 100 Bar)

  • SV1-10/16/120/6 (Size 10, 16 L/min, 120 Bar)

  • SV1-10/32/100/6 (Size 10, 32 L/min, 100 Bar)

  • SV1-10/48/315/6 (Size 10, 48 L/min, 315 Bar – High Pressure/Flow)

• Core Performance Specs:

  • Nominal Sizes: NG6 (Size 06) / NG10 (Size 10).

  • Rated Pressure: 100 Bar, 120 Bar, 210 Bar, up to 315 Bar.

  • Control Command: Analog proportional servo current input.

  • Design Sequence: Series 5 / Series 6.
