Vickers SV1-10 Servo Valve | SV1-10/48/315/6 | SV1-10/32/315/6 | SV1-10/16/210

Vickers Type SV1-10 Series High-Response Direct Drive Servo Valves

Product Overview:

The Vickers SV1-10 Series is a premier precision component in electro-hydraulic control, engineered for closed-loop systems requiring extreme dynamic response and micron-level positioning accuracy. As a standard Size 10 (NG10) valve, this series features Direct Drive technology, where high-force proportional solenoids actuate the micro-ground spool directly. This architecture eliminates pilot-stage complexity and lag, ensuring instantaneous response and exceptional stability even at the maximum 315 Bar operating pressure.

This page features the core flow specifications of the series, including the high-power SV1-10/48, the versatile SV1-10/32, and the precision SV1-10/16.

Key Technical Advantages:

• Ultimate Dynamic Response: The direct-drive design minimizes phase lag, allowing the valve to track complex frequency command signals in real-time.

• High-Pressure Durability: Fully rated for operating pressures up to 315 Bar (4,500 PSI), meeting the stringent load requirements of heavy-duty industrial machinery.

• Precision Null Control: Features micro-ground spool and sleeve assemblies to provide superior linear output and exceptional repetitive positioning accuracy.

• Enhanced Contamination Resistance: Compared to pilot-operated servo valves, the direct-drive structure is more robust against oil particles, significantly extending service life in harsh environments.

Detailed Specifications & Parameters:

• Core Series: Vickers SV1-10 (NG10 / CETOP 05) Series.

• Featured Model Matrix:

  • SV1-10/48/315/6 (Rated Flow: 48 L/min, Max Pressure: 315 Bar)

  • SV1-10/32/315/6 (Rated Flow: 32 L/min, Max Pressure: 315 Bar)

  • SV1-10/16/315/6 (Rated Flow: 16 L/min, Max Pressure: 315 Bar)

  • SV1-10/16/210/6 (Rated Flow: 16 L/min, Pressure Rating: 210 Bar)

• Core Performance Specs:

  • Nominal Size: NG10 (Size 10 / CETOP 05).

  • Rated Pressure: 210 Bar or 315 Bar.

  • Rated Flow: 16, 32, 48 L/min (@ $\Delta p = 70 \text{ Bar}$).

  • Control Command: Analog proportional servo current input.

  • Design Sequence: Series 6.
