Taiyo Hydraulic Cylinder | 160H-12SD32BB300-GA0-KJ | 160H-12SD32BB100 | 16MPa Double Acting

160H-12 Series Heavy-Duty Tie-Rod Hydraulic Cylinders

Product Overview:

The 160H-12 series represents the benchmark for standard tie-rod cylinders engineered for the precision industrial automation of 2026. This collection features the SD32 (32mm Bore) specifications. With a nominal pressure rating of $16 \text{ MPa}$ ($160 \text{ bar}$) and the GA0 high-performance cushioning system, these cylinders excel in mold movement, workpiece clamping, and precision positioning applications.

Core Model Specifications:

• 160H-12SD32BB300-GA0-KJ: $32\text{mm}$ Bore, $300\text{mm}$ Stroke. Features SD (Basic/Tie-rod extended) mounting, GA0 end-position cushioning, and KJ high-durability seals.

• 160H-12SD32BB100-GA0-KJ: $32\text{mm}$ Bore, $100\text{mm}$ Stroke. Compact short-stroke design optimized for confined high-pressure actuation environments.

Key Technical Advantages:

• $16 \text{ MPa}$ Operational Reliability: Built with precision-honed thick-walled barrels and heat-treated tie-rods, ensuring zero mechanical fatigue under the intensive 2026 industrial pulse pressure cycles.

• SD (Basic Type) Mounting: The SD configuration provides extended tie-rods on both ends for excellent axial symmetry, allowing easy integration into custom mechanical frameworks.

• GA0 High-Performance Cushioning: The integrated cushioning system effectively absorbs kinetic energy at the stroke ends, reducing operational noise and protecting the assembly from inertial shock damage.

• KJ Premium Sealing Group: Utilizing KJ-grade specialized seal materials for ultra-low friction. This eliminates “stick-slip” motion at low speeds and provides superior temperature and corrosion resistance.

• Precision Chromed Rods: Rods are hard-chrome plated and precision-ground, offering extreme surface hardness to resist mechanical scratches from industrial dust and debris.

Detailed Technical Specifications:

• Nominal Pressure: $16 \text{ MPa}$ ($160 \text{ bar}$).

• Bore Size: $32 \text{ mm}$.

• Stroke Range: $100 \text{ mm}$ / $300 \text{ mm}$.

• Mounting Style: SD (Basic/Tie-rod).

• Compatible Mediums: Mineral oils, water-glycols, and synthetic lubricants.
