Northman Type SWH-G03 Solenoid Valve | SWH-G03-C2-D24-20 | SWH-G03-C6-A240 | NG10 CETOP 5 Hydraulic Valve

SWH-G03 Series High-Flow Solenoid Directional Control Valves

Product Overview: The SWH-G03 series is a robust range of direct-operated solenoid directional valves engineered for high-flow and high-pressure hydraulic systems. Fully compliant with ISO 4401-05 (NG10 / CETOP 5) international standards, these valves offer exceptional structural integrity. Utilizing wet-pin solenoid technology, the armature operates within the hydraulic fluid, ensuring smooth, low-noise switching and superior heat dissipation for 100% ED (Continuous Duty) cycles. This makes the G03 series a reliable choice for demanding industrial production lines.

Featured models include: SWH-G03-C2-D24-20 and SWH-G03-C6-A240-2.

Key Technical Advantages:

• Superior High-Flow Capacity: As a Size 10 valve, its precision-engineered internal galleries allow flow rates up to 160 L/min, significantly reducing energy loss during switching.

• Versatile Spool Logics: Available in C2 (Closed center) and C6 (P/T connected, A/B blocked) configurations to support complex system pressure-holding and unloading requirements.

• Global Voltage Adaptability: Coils support standard D24 (24V DC) and high-voltage A240 (240V AC), providing strong magnetic force and rapid actuation.

• Proven 20 Design Series: The 20 series features optimized electrical interfaces and higher tank line back-pressure tolerance (up to 16 MPa), making it ideal for system upgrades.

Detailed Specifications & Parameters:

• Featured Model Matrix:

  • SWH-G03-C2-D24-20: Size 10, 3-pos 4-way closed center, 24V DC control, 20 design series.

  • SWH-G03-C6-A240-2: Size 10, 3-pos 4-way P/T connected (unloading spool), 240V AC actuation.

• Core Technical Specs:

  • Mounting Standard: ISO 4401-05 / NG10 / CETOP 5.

  • Max Operating Pressure: Rated at 31.5 MPa (315 bar).

  • Max Flow Capacity: Up to 100 – 160 L/min.

  • Protection Class: Standard IP65 rating.
