Sunfab SAP Series Pump | SAP-064, SAP-056, SAP-084 | High Pressure Piston Pump | SAP-064L-N-DL4

Model Number

SAP-056R-N-DL4-L35-SOS-000

Inquiry

Product Description

Sunfab SAP & SCP Series Lightweight High-Pressure Piston Pumps

Product Overview: The Sunfab SAP and SCP series are the premier choices for global mobile hydraulic applications. Engineered as bent-axis fixed displacement piston pumps, these series are specifically developed for the most demanding Truck Power Take-Off (PTO) environments. Featured models like the SAP-056R-N-DL4-L35-SOS-000 (56cc), SAP-064L-N-DL4-L35 (64cc), and SAP-084L-N-DL4-L35-SOS-000 (84cc) utilize a compact aluminum housing to deliver pressures up to 400 Bar while significantly reducing vehicle weight. These pumps are the core power source for truck-mounted cranes, forestry harvesters, tippers, refuse compactors, and heavy-duty truck hydraulic systems.

Key Technical Advantages:

  • Superior Lightweight Build: The aluminum pump body combined with a compact bent-axis design makes it lighter than traditional cast-iron pumps while offering enhanced heat dissipation.

  • Extreme Operating Pressure: Rated for continuous operation at 400 Bar (5800 PSI), ensuring robust power for heavy lifting and demanding actuation tasks.

  • High-Speed Efficiency: Optimized inlet designs and low-inertia rotating groups allow stable operation at high PTO speeds, effectively preventing cavitation.

  • Weather Resistance & Durability: Equipped with low-temperature seals and anti-corrosion coatings, these pumps are built to withstand extreme environments from Arctic cold to equatorial heat.

  • Standard DIN Compatibility: Strictly adheres to ISO/DIN mounting standards (e.g., DL4/L35 shaft specs), ensuring seamless integration with mainstream truck gearbox PTOs.

Detailed Models & Parameters:

  • Core Series: Sunfab SAP & SCP Series (Bent Axis).

  • Model Keywords: SAP-056, SAP-064, SAP-084, SCP-060, SCP-064, SCP-080.

  • Config Codes: SAP-056R-N-DL4, SAP-064L-N-DL4-L35, SAP-084L-N-DL4-L35-SOS-000.

  • Displacements: 56.5 cm³/rev, 63.5 cm³/rev, 83.6 cm³/rev.

  • Pressure Ratings: Rated at 400 Bar (5800 PSI) continuous; Peak capability up to 450 Bar.

  • Rotation: R (Clockwise/CW); L (Counter-clockwise/CCW).

  • Mounting Standard: DIN 5462 / ISO 7653 (4-hole flange).
