SUN Hydraulics RPCC-LCN | CXJA-XCN | CXKA-XCN | Threaded Pressure Reducing Valve

RPCC & CXJA Series Threaded Pressure Reducing & Check Valves

Product Overview:

This series of precision Threaded Cartridge Valves serves as the backbone of hydraulic manifold design. The RPCC-LCN is a pilot-operated pressure reducing valve that ensures stable, adjustable secondary pressure for downstream circuits, even amidst significant primary system pressure fluctuations. When paired with the CXJA and CXKA series check valves, it facilitates efficient unidirectional flow control and pressure isolation. Manufactured from high-strength alloy steel, these valves offer high response frequencies and superior sealing, making them ideal for injection molding, machine tools, and mobile machinery.

Featured models include: RPCC-LCN, CXJA-XCN, CXJA-LCN, CXJA-XAN, CXJA-XBN, and CXKA-XCN.

Key Technical Advantages:

• Stable Precision Reduction: The RPCC series provides excellent regulation linearity, maintaining precise branch circuit pressure to protect actuators from overload.

• Low Pressure Drop Check Function: CXJA and CXKA check valves feature optimized flow paths for minimal pressure drop at high flow rates, enhancing overall system energy efficiency.

• All-Steel Wear-Resistant Construction: Hardened and ground internal components guarantee outstanding repeatability and zero-leakage performance over millions of cycles.

• Standard Cavity Compatibility: Fits standard T-11A and T-13A SUN-style cavities, enabling rapid installation, replacement, or system upgrades.

Detailed Specifications & Parameters:

• Featured Model Matrix:

  • RPCC-LCN: Pilot-operated reducing valve, L-type adjustment, C-range (up to 210 Bar).

  • CXJA-XCN / CXJA-LCN: Free-flow check valves with multiple cracking pressure options (A/B/C grades).

  • CXKA-XCN: High-capacity check valve optimized for high-flow industrial applications.

• Core Technical Specs:

  • Max Operating Pressure: Rated up to 350 Bar (5000 PSI).

  • Flow Capacity: Approx. 40 L/min for reducing valves; up to 160 L/min for check valves depending on size.

  • Cracking Pressures (Check Valve): A ($0.3\text{ Bar}$), B ($1\text{ Bar}$), C ($2\text{ Bar}$).

  • Seals: Standard Buna-N; Viton (FKM) optional for high-temp environments.
