Sun Hydraulics Valve | CBCG-LJN CXED-XCN CBCA-LHN CBEA-LHN | Load Holding

Sun Hydraulics Counterbalance & Check Valves for Heavy Machinery

Product Overview: Sun Hydraulics Cartridge Valves are globally recognized for their patented “Floating Style” design. This unique construction allows internal components to self-center during installation, neutralizing stresses caused by manifold machining tolerances or excessive torque. This ensures the spool remains sensitive and responsive even under high-pressure conditions up to 350 Bar. This category features premier models for heavy-duty load control: CBCG-LJN, CBCA-LHN, CBEA-LHN (Counterbalance/Load Holding), and CXED-XCN (Direct-acting Check).

Engineered for extreme duty cycles, these screw-in cartridges are the premier choice for excavators, crane outrigger locking, aerial work platforms, mining machinery, and any hydraulic integrated system requiring absolute safety and pressure retention.

Key Technical Advantages:

• Superior Load Management (CB Series): The CBCA and CBEA counterbalance valves provide precise overload protection and controlled load lowering, effectively eliminating actuator drift (cylinder creeping) under heavy loads.

• Patented Floating Technology: The unique two-piece floating construction significantly reduces the risk of spool binding caused by mechanical stress, enhancing operational repeatability.

• Absolute Sealing Integrity (CX Series): Components like CXED-XCN feature precision-honed seats to ensure a zero-leakage, metal-to-metal seal in the reverse position, guaranteeing circuit safety.

• Industrial Durability: Rated for operating pressures up to 350 Bar (5,000 PSI), designed to maintain stable performance in continuous, high-frequency industrial environments.

Detailed Specifications & Parameters:

• Core Series: Sun Hydraulics Load Control & Check Cartridges.

• Featured Model Matrix: CBCG-LJN, CXED-XCN, CBCA-LHN, CBEA-LHN.

• Core Performance Specs:

  • Max Operating Pressure: Rated for heavy-duty operations up to 350 Bar (5,000 PSI).

  • Functional Logic: Counterbalance (CBCG/CBCA/CBEA), Direct Check (CXED).

  • Pilot Ratios: Various options available (e.g., 3:1, 4.5:1) to match actuator inertia.

  • Adjustment Options: L (Leak-proof screw), X (Non-adjustable/Fixed), J (Cap protected).

  • Cavity Standards: Industry-standard cavities such as T-11A, T-2A, T-13A, and T-17A.
