Sun Hydraulics Cartridge Valve | CKCB-XCN CWGG-LGN CWGL-LGN CXDA CXFA | Load Control

Sun Hydraulics CKCB, CWGG, CWGL & CXDA Series Cartridge Valves

Product Overview: Sun Hydraulics Cartridge Valves are globally recognized for their patented “Floating Style” design. This unique construction allows internal components to self-center during installation, neutralizing stresses caused by manifold machining tolerances or excessive torque. This ensures the spool remains sensitive and responsive even under high-pressure conditions up to 350 Bar. This category features premier models for load holding and directional control: CKCB-XCN (Pilot-to-open Check), CWGG-LGN / CWGL-LGN (Counterbalance/Load Holding), and CXDA-XAN / CXFA-XBN (Direct-acting Check).

Engineered for high-pressure, long-life, and severe-duty hydraulic integrated circuits, these screw-in cartridges are the premier choice for construction machinery outrigger locking, crane winch circuits, aerial work platforms, and industrial hydraulic manifolds.

Key Technical Advantages:

• Superior Load Management (CW/CK Series): The CWGG and CWGL counterbalance valves provide precise overload protection and safety locking, effectively eliminating actuator drift under heavy loads.

• Patented Floating Technology: The unique two-piece floating construction significantly reduces the risk of spool binding caused by mechanical stress, enhancing operational repeatability.

• High-Integrity Sealing (CX Series): Components like CXDA and CXFA feature precision-ground seats to ensure a zero-leakage, metal-to-metal seal even at maximum rated pressures.

• Optimized Adjustment (LGN/XCN): Adjustment options like the “L” type leak-proof screw provide superior sensitivity and setting stability during field commissioning.

Detailed Specifications & Parameters:

• Core Series: Sun Hydraulics Load Control & Check Cartridges.

• Featured Model Matrix: CKCB-XCN, CWGG-LGN, CWGL-LGN, CXDA-XAN, CXFA-XBN.

• Core Performance Specs:

  • Max Operating Pressure: Rated for heavy-duty operations up to 350 Bar (5,000 PSI).

  • Functional Logic: Counterbalance (CWGG/CWGL), Pilot-to-open Check (CKCB), Direct Check (CXDA/CXFA).

  • Pilot Ratios: Various ratios available to match specific actuator inertia and load profiles.

  • Sealing Materials: N (Buna-N Standard) or V (Viton options).

  • Cavity Standards: Industry-standard cavities such as T-11A, T-2A, T-5A, and T-17A.
