Sun Hydraulics CBGA, CBCG, CCGA & CBDA Series Cartridge Valves

Product Overview: Sun Hydraulics Cartridge Valves are globally recognized for their iconic “Floating Style” design, which allows internal components to self-center, minimizing internal stress and ensuring sensitive operation under extreme conditions. This category features premier models: CBGA-LHN / CBCG-LJN / CBDA-LHN (Counterbalance), CCGA-LAN (Shuttle valve), CAEA-LHN (Counterbalance), and the CXBA / CXAD precision check elements.

Engineered for high-pressure and long-life hydraulic circuits, these screw-in cartridges integrate seamlessly into custom manifolds. They are the premier choice for construction cranes, aerial work platforms, CNC machinery, and heavy-duty industrial Power Units (HPU).

Key Technical Advantages:

• Floating Cartridge Technology: The unique two-piece floating construction prevents spool binding caused by excessive installation torque, enhancing system reliability.

• Precise Load Holding: The CBGA/CBCG series ensures smooth descent control and zero-drift locking, guaranteeing operational safety.

• Efficient Logic Switching: The CCGA shuttle valve automatically switches between two signal sources with rapid and sensitive response.

• Extended Durability: Hardened and precision-ground internal components ensure long service life even under continuous 350 Bar operational cycles.

Detailed Specifications & Parameters:

• Core Series: Sun Hydraulics Counterbalance, Check & Shuttle Cartridges.

• Featured Model Matrix: CCGA-LAN, CAEA-LHN, CXBA-XCN, CXAD-XCN, CBGA-LHN, CBCG-LJN, CBDC-LHN, CBDA-LHN, CBFG-LJN.

• Core Performance Specs:

  • Max Operating Pressure: Rated for heavy-duty operations up to 350 Bar (5,000 PSI).

  • Functional Logic: Shuttle Control (CCGA), Counterbalance (CBGA/CBCG/CBDA/CBFG), Fixed Check (CXBA/CXAD).

  • Adjustment Options: L (Leak-proof screw), X (Non-adjustable).

  • Pilot Ratios: Various ratios (e.g., 3:1, 4.5:1) available to match specific motion smoothness requirements.

  • Cavity Standards: Industry-standard cavities such as T-11A, T-2A, T-17A, and T-10A.
