16MPa Stainless Steel Cylinder | 160H-1 2LA50BB100-GAB | 3.25D3LCTS14A4.500 | Double Acting

160H-1 & 3LCT Series Stainless Steel Hydraulic Cylinders

Product Overview:

This series represents the premier $16 \text{ MPa}$ class double-acting cylinders engineered for the harsh corrosive environments of 2026, including offshore operations, food processing, and chemical sectors. Featuring the Taiyo 160H-1 standard tie-rod series and 3LCT custom stainless specifications, these units provide precise power output even under high humidity or chemical spray conditions.

Core Model Specifications:

• 160H-1 2LA50BB100-GAB-TK-J: $50\text{mm}$ Bore, $100\text{mm}$ Stroke. Features LA (Foot Mount), GAB advanced cushioning, and TK-J grade wear-resistant seals.

• 3.25D3LCTS14A4.500: Custom $3.25\text{in}$ Bore stainless cylinder with $4.5\text{in}$ Stroke. Part of the high-strength 3LCT lightweight series.

• 1.50DB 3LCT14A0.125: Compact $1.50\text{in}$ Bore with an ultra-short $0.125\text{in}$ Stroke, designed for precision limit-stopping and confined space locking.

Key Technical Advantages:

• Full Stainless Corrosion Resistance: Critical components (barrel, rods, tie-rods) are crafted from high-grade stainless steel to resist oxidation and acid/alkali exposure, meeting the latest 2026 global hygiene and environmental standards.

• 16MPa (160 bar) Double-Acting Power: Rated at $16 \text{ MPa}$, the double-acting design ensures robust, controlled hydraulic force in both extension and retraction strokes.

• GAB Precision Cushioning: Provides progressive deceleration at stroke ends, effectively eliminating vibration from mechanical impact and extending the fatigue life of precision structures.

• TK-J High-Performance Sealing: Specifically optimized for stainless steel bores, these seals offer a low friction coefficient and superior internal bypass prevention, eliminating “stick-slip” motion.

• Exceptional Customization: Ranges from Metric ($50\text{mm}$) to Imperial ($3.25\text{in}$) sizes, catering to everything from heavy-duty lifting to precision micro-actuation.

Detailed Technical Specifications:

• Nominal Pressure: $16 \text{ MPa}$ ($160 \text{ bar}$).

• Bore Sizes: $32 \text{ mm}$ to $100 \text{ mm}$ / $1.50 \text{ in}$ to $3.25 \text{ in}$.

• Stroke Range: $0.125 \text{ in}$ to $100 \text{ mm}$ (Custom lengths available).

• Material: Premium Stainless Steel / Chrome-plated alloy.

• Mounting Styles: LA (Foot Mount) / DB (Rear Mount) / TC (Trunnion).
