Second-hand ESHG-06 Servo Valve | ESHG-06-2-320-ET | ESHG-06-2B-110 | Tested & Refurbished | High Response

Second-hand & Refurbished ESHG-06 Series Proportional Servo Valves

Product Overview:

The ESHG-06 series comprises high-response proportional servo valves engineered for closed-loop control in demanding applications like die-casting, injection molding, and heavy-duty pressing. Our inventory of second-hand and refurbished ESHG valves undergoes rigorous hydraulic bench testing and frequency response validation to ensure peak operational performance. These inspected units offer a cost-effective alternative to brand-new components while providing a critical solution for sourcing discontinued or hard-to-find models.

Featured models include: ESHG-06-2-320-ET-1019, ESHG-06-2B-110-E-M-1R, and ESHG-06-2-320-ET-1012.

Key Technical Advantages:

• Servo-Level Dynamics: Equipped with high-frequency solenoids that deliver ultra-fast step response and minimal hysteresis for precise actuator positioning.

• Cost-Effective Spare Parts: For specific design series like 1019 and 1012, we offer hand-picked original used units, providing a “plug-and-play” solution that minimizes machine downtime.

• Flexible Pilot/Drain Configurations: Available in ET (Internal Pilot/Internal Drain) and E-M (External Control) variants to match complex integrated manifold designs.

• Strict Quality Assurance: Every second-hand ESHG valve is tested for zero-offset, linearity, and internal leakage before dispatch.

Detailed Specifications & Parameters:

• Featured Model Matrix:

  • ESHG-06-2-320-ET-1019: Size 20, rated flow 320 L/min, features internal pilot and drain.

  • ESHG-06-2B-110-E-M-1R: 2-position function, rated flow 110 L/min, equipped with manual override.

  • ESHG-06-2-320-ET-1012: 320 L/min capacity specification, classic 1012 design series.

• Core Technical Specs:

  • Max Operating Pressure: 31.5 MPa (315 bar).

  • Rated Flow Capacity: 110 L/min to 320 L/min (at $\Delta p=1 MPa$).

  • Control Signal: Compatible with standard proportional amplifier current signals.

  • Mounting Interface: Compliant with ISO 4401-06 (Size 20) standards.
