Rexroth Type PVV1 Vane Pump | PVV1-1X/027, PVV1-1X/046 | R900936954

Rexroth Type PVV1 Series Compact High-Performance Vane Pumps

Product Overview: The Rexroth Type PVV1 Series fixed displacement vane pump is the premier choice for achieving precision power and silent operation in industrial hydraulic systems worldwide. Designed as a classic compact industrial power source, the PVV1 is engineered specifically for medium-to-high pressure and continuous duty. This selection features core specifications: PVV1-1X/027RA15UMB (Part No. R900936954) and PVV1-1X/046RJ15UMB. Utilizing a hydraulically balanced core design, the PVV1 maintains maximum volumetric efficiency and significantly reduces system vibration even at pressures up to 21.0 MPa (210 Bar).

Key Technical Advantages:

• Ultimate Quiet & Low Pulsation: The optimized stator curve paired with a 12-vane rotor effectively suppresses flow pulsations, keeping operational decibels far below comparable gear pumps—ideal for enhancing workshop environments.

• Modular “Drop-in” Cartridge Maintenance: The internal pump core is a self-contained unit. Maintenance is streamlined—swap the internal cartridge on-site to restore performance without disconnecting heavy plumbing, drastically cutting downtime.

• High-Pressure Longevity: Rated for pressures up to 210 Bar. The hydraulically balanced rotor design neutralizes radial loads, ensuring extreme bearing reliability under continuous duty cycles.

• Compact & Easy Integration: With high power density and compact mounting dimensions, the PVV1 is perfectly suited for space-constrained automated equipment and small Hydraulic Power Units (HPU).

• Target Applications: CNC machine tools, shoemaking machinery, compact presses, plastic molding equipment, hydraulic clamping systems, and automated production lines.

Detailed Models & Parameters:

• Core Series: Rexroth Type PVV1 Series (Fixed Displacement).

• Model/Part Keywords: PVV1-1X/027, PVV1-1X/046, R900936954.

• Displacement Ratings (cm³/rev): 27 cm³/rev (027) / 46 cm³/rev (046).

• Technical Specs Decoding:

  • 1X: Current component series identifier.

  • R: Right-hand (Clockwise) rotation direction.

  • A15 / J15: Standard mounting flange and specific drive shaft types.

  • UMB: Porting connection styles and seal configurations.

• Max Operating Pressure: Rated for continuous operation up to 21.0 MPa (210 Bar / 3050 PSI).

• Speed Range: Supports stable operation between 600 and 1800 RPM.
