Rexroth Type PVV Series Vane Pump | PVV5-1X/193, PVV21-1X/040-018 | 210 Bar

Rexroth Type PVV Series Heavy-Duty Industrial Fixed Vane Pumps

Product Overview: The Rexroth Type PVV Series fixed displacement vane pump is the global benchmark for power and reliability in heavy-duty industrial hydraulic systems. Designed specifically for high-pressure, high-displacement, and continuous heavy-load operation, the PVV series is a powerhouse of the Rexroth lineup. This selection features premium models: PVV5-1X/193RA15UMC (Ultra-high flow single pump) and PVV21-1X/040-018RA15UUMB (Precision double pump, Part No. R900937332). Utilizing precision-ground port plates and a hydraulically balanced core, the PVV series maintains maximum volumetric efficiency and significantly reduces system noise even at continuous operating pressures up to 21.0 MPa (210 Bar).

Key Technical Advantages:

• Superior High-Flow Output (PVV5): Delivers robust flow rates of up to 193 cm³/rev, perfectly suited for high-speed movements of massive heavy-duty actuators.

• Flexible Dual-Circuit Control (PVV21): The double pump architecture allows two different displacement cartridges (e.g., 40 and 18 cm³/rev) on a single shaft, ideal for independent high-low pressure synergy and energy optimization.

• Ultimate Quiet & Low Pulsation: Optimized stator curves paired with a multi-vane rotor system effectively suppress flow pulsations, keeping operational decibels far below industry standards.

• Rapid “Drop-in” Cartridge Maintenance: The internal pump core is a self-contained unit. Maintenance is streamlined—swap the internal cartridge on-site to restore performance without disconnecting heavy plumbing, drastically cutting downtime.

• Target Applications: Large-scale injection molding machines, metal shears, brick presses, rubber machinery, and heavy industrial Hydraulic Power Units (HPU).

Detailed Models & Parameters:

• Core Series: Rexroth Type PVV Series (PVV5, PVV21).

• Model/Part Keywords: PVV5-1X/193, PVV21-1X/040-018, R900937332.

• Displacement Ratings (cm³/rev):

  • PVV5-193: Single pump displacement 193 cm³/rev.

  • PVV21-040-018: Double pump P1 end 40 cm³/rev, P2 end 18 cm³/rev.

• Technical Specs Decoding:

  • 1X: Current component series identifier.

  • R: Right-hand (Clockwise) rotation direction.

  • A15: Standard mounting flange and drive shaft specification.

  • UMC / UUMB: Porting connection styles and seal configurations.

• Max Operating Pressure: Rated for continuous operation up to 21.0 MPa (210 Bar / 3050 PSI).

• Speed Range: Supports stable operation between 600 and 1800 RPM.
