Rexroth Type PVV Vane Pump | PVV5-1X/193, PVV41-1X/082-018 | 210 Bar

Rexroth Type PVV Series Heavy-Duty Industrial Fixed Vane Pumps

Product Overview: The Rexroth Type PVV Series fixed displacement vane pump is the global industry standard for power and reliability in heavy-duty industrial hydraulic systems. Designed specifically for high-pressure, high-displacement, and continuous heavy-load operation, the PVV series is a powerhouse of the Rexroth industrial lineup. This selection features core specifications: PVV5-1X/193RA150VC (Ultra-high flow single pump) and PVV41-1X/082-018RA15UUMC (Precision high-low double pump). Utilizing a hydraulically balanced core, the PVV series maintains maximum volumetric efficiency and significantly reduces system vibration even at continuous operating pressures up to 21.0 MPa (210 Bar).

Key Technical Advantages:

• Superior High-Flow Output (PVV5): Delivers robust flow rates of up to 193 cm³/rev, perfectly suited for high-speed movements of massive heavy-duty actuators.

• Efficient Dual-Circuit Control (PVV41): The double pump architecture allows two different displacement cartridges (e.g., 82 and 18 cm³/rev) on a single shaft, ideal for independent high-low pressure synergy and energy optimization.

• Ultimate Quiet & Low Pulsation: Acoustically optimized stator curves effectively suppress flow pulsations, keeping operational decibels far below comparable gear pumps—ideal for improving workshop environments.

• Modular “Drop-in” Cartridge Maintenance: The internal pump core is a self-contained unit. Maintenance is streamlined—swap the internal cartridge on-site without disconnecting heavy plumbing, drastically cutting downtime.

• Target Applications: Large-scale injection molding machines, metal shears, brick presses, hydraulic guillotines, and heavy industrial Hydraulic Power Units (HPU).

Detailed Models & Parameters:

• Core Series: Rexroth Type PVV Series (Fixed Displacement).

• Model Keywords: PVV5-1X/193, PVV41-1X/082-018, 193RA150VC, 082-018RA15UUMC.

• Displacement Ratings (cm³/rev):

  • PVV5-193: Single pump displacement 193 cm³/rev.

  • PVV41-082-018: Double pump P1 end 82 cm³/rev, P2 end 18 cm³/rev.

• Technical Specs Decoding:

  • 1X: Current component series identifier.

  • R: Right-hand (Clockwise) rotation direction.

  • A15: Standard mounting flange and drive shaft specification.

  • 0VC / UUMC: Porting connection styles and specific sealing configurations.

• Max Operating Pressure: Rated for continuous operation up to 21.0 MPa (210 Bar / 3050 PSI).

• Speed Range: Supports stable operation between 600 and 1800 RPM.
