Rexroth Type 4WE6 Valve | 4WE6E 4WE6J 4WE6G 4WE6D 4WE6H | NG6 Solenoid Valve | DC24V

Rexroth Type 4WE6 Series Solenoid Operated Directional Control Valves

Product Overview: The 4WE6 Series is the global industry standard for direct-acting solenoid spool valves, engineered to control the start, stop, and direction of hydraulic actuators. Fully compliant with ISO 4401-03 (NG6 / CETOP 3) mounting standards, these valves are renowned for their exceptional reliability, modular interchangeability, and compact footprint.

This category features a comprehensive range of spool configurations, including the popular 4WE6E (closed center), 4WE6G (P-blocked), 4WE6J (Y-type), and specialized logic models such as H, U, T, and D. Equipped with high-performance EG24 (DC24V) wet-pin solenoids and N9K4 (DIN connectors), this series ensures long-term stability for injection molding machines, machine tools, hydraulic power units (HPUs), and automated industrial equipment.

Key Technical Advantages:

• Wet-Pin Solenoid Design: The armature operates fully immersed in hydraulic oil, ensuring superior heat dissipation, minimal switching shock, reduced noise, and an extended coil life cycle.

• Complete Spool Logic Portfolio: Available in E, J, H, G, U, T, and D functions, meeting all control requirements from system unloading and pressure holding to differential circuits.

• Superior Protection (IP65): The N9K4 electrical interface provides robust protection against moisture and dust, ensuring reliable operation in harsh factory environments.

• Manual Override Capability: Standard manual override push-buttons allow for spool actuation during power outages or during the system commissioning and troubleshooting phase.

Detailed Specifications & Parameters:

• Core Series: Rexroth Type 4WE6 Solenoid Operated Valve.

• Featured Model Matrix: 4WE6G62/EG24N9K4, 4WE6E, 4WE6J, 4WE6H, 4WE6G, 4WE6U, 4WE6T, 4WE6D.

• Core Performance Specs:

  • Nominal Size: Size 6 / NG6 / CETOP 3.

  • Max Operating Pressure: Ports A, B, and P rated up to 315 Bar (4,500 PSI).

  • Max Flow Capacity: Up to 80 L/min (depending on spool type).

  • Operating Voltage: EG24 (DC 24V).

  • Mounting Pattern: Complies with ISO 4401-03-02-0-05.
