Rexroth Type 1PV Series Pilot Variable Vane Pump | 1PV2V4-20, 1PV2V3-40 | 16MPa

Rexroth Type 1PV Series Pilot-Operated Variable Displacement Vane Pumps

Product Overview: The 1PV Series is a high-performance Pilot Operated Variable Vane Pump engineered for industrial hydraulic systems requiring precise pressure regulation and high-efficiency output. Compared to standard direct-acting pumps, the pilot control mechanism ensures a smoother transition during pressure compensation and exceptional repeatability. This page features the core specifications: 1PV2V4-20/20RA01MC1-16A1 and 1PV2V3-30/40RA01MC63A1. With its precision-ground port plates, the 1PV series maintains superior volumetric efficiency and minimizes system heat generation even at continuous operating pressures up to 16.0 MPa (160 Bar).

Key Technical Advantages:

• Precision Pilot Control: The integrated pilot pressure regulator provides narrow pressure cut-off hysteresis, ensuring actuator precision at critical pressure limits.

• Exceptional Energy Efficiency: Delivers “Oil on Demand.” When the system reaches the preset pressure, displacement automatically reduces to a compensation state, eliminating the energy waste typical of relief valves.

• High-Pressure Durability: The 1PV2V4 series supports rated pressures up to 16.0 MPa, significantly higher than the 7.0 MPa limit of conventional variable vane pumps.

• Low Noise & Extended Life: Utilizing a hydrostatically balanced structure, the pump suppresses pressure pulsations, effectively extending the service life of bearings and internal cartridges.

• Target Applications: Precision machine tools, automated production lines, hydraulic clamping systems, test benches, and energy-saving Hydraulic Power Units (HPU).

Detailed Models & Parameters:

• Core Series: Rexroth Type 1PV Series (1PV2V3, 1PV2V4).

• Model Keywords: 1PV2V4-20/20RA01MC1-16A1, 1PV2V3-30/40RA01MC63A1.

• Displacement & Flow Ratings:

  • 1PV2V4-20/20: Base displacement and rated flow configuration of 20 cm³/rev class.

  • 1PV2V3-30/40: Specific flow setting within the 40 cm³/rev frame size.

• Technical Specs Decoding:

  • R: Right-hand (Clockwise) rotation.

  • A01: Standard mounting flange and shaft end configuration.

  • MC1 / MC63: Pilot-operated regulator types (MC1 typically for 16MPa).

  • 16A1 / 63A1: Design sequence and maximum pressure setting indicators.

• Pressure Range: Operating from 6.3 MPa (63 Bar) up to 16.0 MPa (160 Bar).
