Rexroth Filter | R928006843 | 2.0160-PWR3-B00-0-V | 2.0160-PWR6-B00-0-V | High Pressure Element

Rexroth 2.0160 Series PWR High-Performance High-Pressure Filters

Product Overview:

This series of pleated filter elements is specifically engineered for Bosch Rexroth 2.0160 size housings, serving as a critical component for maintaining the cleanliness of servo-hydraulic systems and high-response proportional valves. In 2026, across precision machine tools, wind power controls, and aerospace hydraulics, these elements—utilizing patented PWR (Betamicron®) technology—ensure fluid integrity strictly adheres to ISO 4406 standards, preventing valve stiction and premature pump wear.

Featured models: R928006843 (2.0160-PWR3-B00-0-V) and 2.0160-PWR6-B00-0-V.

Key Technical Advantages:

• PWR Extreme Media Technology: Features next-generation gradient-structured composite glass fiber. PWR3 offers an absolute $3\mu\text{m}$ rating, while PWR6 provides $6\mu\text{m}$ precision. Both achieve a $\beta_x(c) \ge 1000$ efficiency.

• B00 Bypass & V-Grade Viton Seals: Equipped with a B00 bypass valve (typically $6 \text{ bar}$ opening pressure) to safeguard the system under abnormal pressure surges. The V suffix denotes high-performance Viton (FKM) seals, offering superior thermal and chemical resistance, ideal for specialized fluids like phosphate esters.

• Deep Pleated Design: Optimized pleat geometry maximizes the effective filtration area, delivering massive Dirt Holding Capacity while maintaining a low pressure drop, significantly reducing maintenance frequency.

• High Collapse Stability: Reinforced stainless steel or galvanized inner cores provide superior mechanical strength, handling instantaneous pressure pulses and high-viscosity cold starts with ease.

• $100\%$ Physical Interchangeability: Manufactured to strict industrial dimensional standards to guarantee a perfect fit with original Rexroth filter housings and interface standards.

Detailed Specifications & Parameters:

• Featured Model Matrix:

  • R928006843: Size 2.0160, PWR3 ultra-precision, $3\mu\text{m}$ rating.

  • 2.0160-PWR6-B00-0-V: Size 2.0160, PWR6 high-precision, $6\mu\text{m}$ rating.

• Technical Specifications:

  • Filtration Rating: $3\mu\text{m}$ or $6\mu\text{m}$ (Absolute).

  • Beta Rating ($\beta$ value): $\beta \ge 1000$.

  • Seal Material: Viton/FKM (V-Grade).

  • Operating Temperature: $-20^\circ\text{C}$ to $+120^\circ\text{C}$.
