Rexroth Hydraulic Cylinder | CDH1MP5/160/110/700 | CDH3 CDM1 CDL1 CDT3 | CD210H4025

color

Blue, Black, Pink, Orange, Purple, Plum

Inquiry

Product Description

Rexroth Series Heavy-Duty Hydraulic Cylinders (CDH1/CDM1/CDL1/CD210)

Product Overview:

This series is engineered for extreme 2026 industrial environments including metallurgy, molding, heavy engineering, and automated control systems. It covers the full spectrum from tie-rod designs (CDH1/CDH3/CDT3) to rounded mill-type structures (CDM1/CDL1) and high-pressure compact units (CD210). A highlight is the CDH1MP5/160/110/700A1X, known for its robust power output and sealing stability, ensuring zero downtime during continuous operations.

Core Models & Series Covered:

  • Heavy-Duty Series (CDH1): CDH1MP5/160/110/700A1X/B1CGDMWW (Bore 160mm / Rod 110mm / Stroke 700mm).

  • Standard & Compact Series: CDH3, CDM1, CDL1, CDT3.

  • High-Pressure Series: CD210H4025-65Z1X01H ($21 \text{ MPa}$ Class).

Key Technical Advantages:

  • Diverse Structural Configurations: * CDH/CGH Series: Robust tie-rod design offering exceptional serviceability.

    • CDM/CDL Series: Rounded mill-type construction, ideal for high-pressure applications in confined spaces.

    • CD210 Series: Optimized for $210 \text{ bar}$ pressure levels, featuring a compact, impact-resistant frame.

  • Extreme Load Capacity: The CDH1 features a $160\text{mm}$ Bore and $110\text{mm}$ Rod, generating massive thrust at $25 \text{ MPa}$ for heavy presses and shearing equipment.

  • B1CGD Composite Sealing: Utilizing a low-friction, high-wear resistant sealing system that prevents internal bypass, significantly extending maintenance intervals in intensive 2026 industrial cycles.

  • 1X/Z1X Design Optimization: Strictly follows Rexroth’s latest design standards, ensuring $100\%$ physical interchangeability and reducing spare parts overhead.

  • Precision Chromed Rods: All piston rods are induction-hardened and hard-chrome plated for superior corrosion resistance and high side-load tolerance.

Detailed Specifications:

  • Pressure Ratings: $16 \text{ MPa}, 25 \text{ MPa}, 31.5 \text{ MPa}$ (Series dependent).

  • Bore/Rod Sizes: $160 / 110 \text{ mm}$ (Example).

  • Stroke Range: Up to $700 \text{ mm}$ and customized lengths.

  • Mounting Styles: MP5 (Rear Clevis), MF3 (Head Flange), etc.

  • Seal Material: Viton (FKM) or Nitrile (NBR).
