Rexroth CD210 Cylinder | CD210H100/70-50 | CD210C50/36-280 | 21MPa Hydraulic

CD210 Series Heavy-Duty High-Pressure Hydraulic Cylinders

Product Overview:

The CD210 series is a compact, heavy-duty hydraulic cylinder range engineered for 2026 high-pressure automation, die-casting, and metallurgical applications. This collection features the CD210H and CD210C series, optimized for $21 \text{ MPa}$ (210 bar) nominal pressure. Known for its exceptional structural integrity and service life, it is the premier choice for precision industrial drive units.

Core Model Specifications:

• CD210H100/70-50Z1X/13HEDM1-1A: $100\text{mm}$ Bore, $70\text{mm}$ Rod, $50\text{mm}$ Stroke. Utilizing the Z1X design series for maximum rigidity.

• CD210C50/36-280.0Z11/13HEDM1-1A: $50\text{mm}$ Bore, $36\text{mm}$ Rod, $280\text{mm}$ Stroke. Utilizing the Z11 design series for smoother operation in long-stroke configurations.

Key Technical Advantages:

• $21 \text{ MPa}$ Class High-Pressure Power: Optimized for medium-to-high pressure cycles. The barrels are crafted from high-strength cold-drawn tubes to ensure minimal deformation in 2026 heavy-duty operations.

• Versatile H/C Mounting Styles:

  • CD210H: Features flange mounting for reliable axial force transmission.

  • CD210C: Robust foot mounting designed to withstand lateral force components in demanding environments.

• EDM1 Advanced Sealing: Equipped with high-wear resistant composite seals. The low friction coefficient ensures smooth operation even at ultra-low speeds while eliminating internal bypass leakage under high pressure.

• Precision Chromed Rods: Rods are induction-hardened and hard-chrome plated, offering superior surface hardness and excellent protection against mechanical damage and corrosion.

• Global Interchangeability: Manufactured strictly to Rexroth CD series industrial tolerances, ensuring a seamless fit for OEM replacements and reducing maintenance downtime.

Detailed Technical Specifications:

• Nominal Pressure: $21 \text{ MPa}$ ($210 \text{ bar}$).

• Bore/Rod Ratios: $100/70, 50/36 \text{ mm}$ (Optimized for force-area efficiency).

• Strokes: From $50\text{mm}$ (Short-stroke control) to $280\text{mm}$ (Long-stroke reciprocating).

• Design Series: 1X / 11 Series.

• Sealing Type: EDM1 Standard High Pressure.
