Rexroth A6VM Series High-Pressure Variable Bent Axis Motors

Product Overview:

The Rexroth A6VM Series is globally recognized as the technology benchmark for bent-axis variable axial piston motors. Designed for both open and closed-circuit hydrostatic transmissions, the A6VM series achieves a perfect balance between high startup torque and high-speed transit through its expansive displacement ratio ($V_{max}/V_{min}$). This category covers the full spectrum from the compact A6VM55 to the heavy-duty A6VM250. These motors are the definitive power units for crawler excavator travel drives, rotary drill rig power heads, large crane winches, and road machinery.

Key Technical Advantages:

• Superior Displacement Ratio: Features expansive variability, supporting stepless adjustment from maximum to minimum displacement to significantly improve machine efficiency and fuel economy.

• Precision Control Modules:

  • EP2 (Electric Proportional): Achieves precise electronic displacement adjustment via proportional solenoids, ideal for integration with modern electronic control systems.

  • HD2 (Hydraulic Proportional): Provides linear displacement adjustment based on pilot pressure signals for refined operator feedback.

• Extreme Pressure Resilience: Rated for a continuous operating pressure of 400 Bar with peak capabilities reaching 450 Bar (6500 PSI), built to withstand intense shock loads in harsh environments.

• Elite Power Density: The compact bent-axis design delivers massive torque within a minimal footprint and ensures excellent cold-start performance.

• Target Applications: Excavator travel drives, industrial winches, pavers, rollers, and mining machinery.

Detailed Models & Parameters:

• Core Series: Rexroth A6VM Series 63 (Series 6).

• Technical Spec Decoding:

  • A6VM107EP2/63-VSD510DTB-S: Size 107, EP2 electric control, featuring VSD510 specialized shaft and sensor interfaces.

  • A6VM160HD2/63W-VSD52000B: Size 160, HD2 hydraulic control, with VSD520 reinforced output shaft.

• Common Sizes: A6VM55, A6VM80, A6VM107, A6VM160, A6VM250.

• Core Performance Specs:

  • Displacement Range: 55 cm³ to 250 cm³/rev.

  • Max Speed: Up to 4000+ RPM (depending on frame size and displacement).
