Rexroth A2FLM Series Large Displacement Bent-Axis Fixed Motors

Product Overview: The Rexroth A2FLM Series is the ultimate solution for “heavy-duty power” requirements in the hydraulic drive industry. Utilizing proven Bent-Axis technology, these motors are specifically engineered to deliver massive torque and handle extreme industrial loads. This selection highlights three flagship configurations: A2FLM500/60W-VZH010, A2FLM710/60W-VZH010, and the top-tier A2FLM1000/60W-VPH010. Renowned for their exceptional power-to-weight ratio and the rugged Series 60 design, the A2FLM series is the premier choice for ultra-large crane winches, TBM drives, large-scale mixing systems, mining equipment, and marine propulsion.

Key Technical Advantages:

• Ultra-Large Displacement Range: Offers displacements from 500cc to 1000cc, capable of delivering staggering mechanical torque without requiring excessive flow rates.

• Bent-Axis Efficiency: The optimized bent-axis architecture ensures industry-leading volumetric and mechanical efficiency, maintaining smooth operation even under extreme pressure.

• Extreme Pressure Resilience: Rated for continuous operation at 350 Bar (5000 PSI) with peak pressures reaching 400 Bar, built to withstand high-frequency shock loads in industrial environments.

• Heavy-Duty Bearing System: Equipped with specialized reinforced bearings that handle massive external radial loads, significantly extending service intervals under high-load cycles.

• Target Applications: Heavy-duty winch drives, open-pit mining machinery, large Tunnel Boring Machines (TBM), marine deck cranes, and offshore platform equipment.

Detailed Models & Parameters:

• Core Series: Rexroth A2FLM Series 60 (Large Displacement).

• Model Keywords: A2FLM500, A2FLM710, A2FLM1000, VZH010, VPH010.

• Technical Specs Decoding:

  • A2FLM500/60W-VZH010: 500cc displacement, Series 60, featuring VZH specialized splined shaft configuration.

  • A2FLM710/60W-VZH010: 710cc displacement, optimized for heavy-duty systems requiring higher torque.

  • A2FLM1000/60W-VPH010: 1000cc maximum displacement, featuring VPH standard high-pressure ports and shaft ends.

• Pressure Specs: Nominal Pressure 350 Bar (35 MPa), Peak Pressure 400 Bar (5800 PSI).

• Displacement Range: 500 cm³/rev, 710 cm³/rev, 1000 cm³/rev.
