Rexroth A17FO Series Pump | A17FO032, A17FO023 | 10MLWK0E81-0 | Fixed Displacement Piston Pump

Rexroth A17FO Series Fixed Displacement Axial Piston Pumps

Product Overview: The Rexroth A17FO series is a high-pressure, bent-axis axial piston fixed displacement pump specifically engineered for open-circuit hydraulic systems. Renowned for its ultra-compact design and exceptional power-to-weight ratio, this series is the preferred power source for truck-mounted cranes, loaders, municipal vehicles, and industrial manufacturing machinery. Featured models like the A17FO032/10MLWK0E81-0 and A17FO023/10NLWK0E81-0 utilize a 7-piston rotating group to ensure smooth flow delivery and low operational noise even under continuous high-pressure conditions of up to 350 Bar.

Key Technical Advantages:

• Ultra-Compact Bent-Axis Design: The unique bent-axis geometry enhances mechanical efficiency while significantly reducing physical dimensions, making it ideal for constrained PTO (Power Take-Off) mounting spaces on truck chassis.

• Heavy-Duty Pressure Ratings: Rated for continuous operation at 350 Bar (5000 PSI) with peak capabilities up to 400 Bar, easily managing heavy-duty lifting and crushing cycles.

• Superior Suction Characteristics: Hydrodynamically optimized intake ports provide excellent self-priming performance at high speeds, effectively minimizing the risk of cavitation.

• Low Noise & Extended Service Life: Equipped with reinforced bearings and wear-resistant piston groups to suppress hydraulic ripples and mechanical noise, extending the time between overhauls.

• 100% Standardized Compatibility: Manufactured to strict ISO mounting specifications (e.g., WK0E81 interface series), ensuring splined shafts and flanges align perfectly with global OEM systems (SCANIA, VOLVO, MAN).

Detailed Models & Parameters:

• Core Series: Rexroth A17FO Series 10.

• Model Keywords: A17FO032/10MLWK0E81-0, A17FO023/10NLWK0E81-0.

• Displacements: 23.0 cm³/rev (A17FO023) / 32.0 cm³/rev (A17FO032).

• Pressure Ratings: Rated at 350 Bar (5000 PSI) continuous; Peak capability up to 400 Bar.

• Maximum Speed: Up to 2300 – 2500 RPM (depending on model).

• Target Applications: Truck cranes, refuse compactors, timber loaders, and industrial Open-Circuit Hydraulic Power Units (HPU).
