Rexroth A10VSO71 Pump | Axial Piston Variable Displacement Pump | 71cc High Pressure Plunger Pump
| horsepower | Customizable |
|---|---|
| Flow Rate | Customizable |
| maximum head | Customizable |
Product Description
Rexroth A10VSO71 Axial Piston Variable Displacement Pumps
Product Overview: The Rexroth A10VSO71 is a legendary swashplate axial piston variable pump engineered for open-circuit industrial hydraulic systems. As a cornerstone of the A10V family, the A10VSO71 is globally recognized for its exceptional “Power-to-Weight Ratio” and “Extended Service Life.” With a displacement of 71 cm³/rev and a rated pressure of 28 MPa, its modular design supports various control options (e.g., DFR1 Load Sensing, DR Pressure Control), precisely modulating flow to match real-time demand. It is the premier power source for metal forming tools, injection molders, woodworking machinery, and diverse industrial Hydraulic Power Units (HPU).
Key Technical Advantages:
Superior Energy Efficiency: Achieves perfect displacement matching via precision variable controls (like Load Sensing), significantly reducing system heat and power consumption.
Whisper-Quiet Operation: Features an optimized decompression valve plate design, maintaining ultra-low decibel output even under full load at high pressures.
Excellent Suction Characteristics: The unique internal architecture ensures superior self-priming performance at rated speeds, effectively preventing cavitation.
High Interchangeability: Strictly adheres to ISO/SAE mounting standards, ensuring that flanges, shafts, and ports align perfectly for a 100% “drop-in” replacement.
Rugged Contamination Resistance: Built with high-strength ductile iron housings and wear-resistant piston groups for stable performance in harsh industrial environments.
Detailed Models & Parameters:
Core Series: Rexroth A10VSO Series (Size 71).
Model Keywords: A10VSO71DR, A10VSO71DFR1, A10VSO71DFE1, A10VSO71DRG.
Displacement: 71 cm³/rev (4.33 in³/rev).
Pressure Ratings: Rated at 280 Bar (4000 PSI) continuous; Peak capability up to 350 Bar (5100 PSI).
Control Types: DR (Pressure Control), DFR/DFR1 (Pressure & Flow Control), DFE1 (Electro-hydraulic Control).
Target Applications: CNC press brakes, plastic processing equipment, aluminum extruders, and power plant HPUs.
Purchase need
1.The company brand model series is complete, many do not have one by one you need what type of product, please contact customer service.
2.We hope that our products is your right product, we are responsible for you is also responsible for our own, and every cooperation is the source of our company’s life.
Product Features:
1. Axial piston pump with swashplate design for hydraulic drive in open circuit
2. Optional installation location
3. Excellent oil absorption characteristics
4. Low noise level
5. Long service life
6. Modular design
7. Short response time
8. Variable speed drive options
9. Visible swing angle indicator
10. The flow rate is proportional to the input transmission speed and displacement. By adjusting the swashplate angle, the output flow can be steplessly adjusted.
11. Use of HF oil in the case of reduced operating data There is a special model that can be used to run with HFC oil
