Rexroth A10FM63 Motor | A10FM63/52R-VWC66N002-S2540 | Axial Piston Fixed Motor

Rexroth A10FM63/52R Fixed Displacement Axial Piston Hydraulic Motors

Product Overview: The Rexroth A10FM Series is a high-performance, swashplate-designed fixed displacement motor specifically engineered for hydrostatic drives. Built on the proven A10 technical platform, the A10FM63 delivers impressive power density within a compact frame. This page features the high-precision model: A10FM63/52R-VWC66N002-S2540. Characterized by an output speed proportional to the input flow, this motor is widely utilized in auxiliary drives for construction machinery, fan drive circuits, light-duty winches, and industrial mixing systems. Its highly standardized design ensures superior compatibility across complex hydraulic architectures.

Key Technical Advantages:

• High-Efficiency Axial Piston Design: The swashplate architecture ensures exceptional volumetric and mechanical efficiency while delivering consistent rotation.

• Elite Power-to-Weight Ratio: The compact housing allows for installation in space-restricted environments without compromising torque output.

• Superior Noise Reduction: Optimized port plate geometry effectively suppresses fluid pulsation, resulting in quieter and smoother operation.

• Wide Application Scope: Suitable for both open and closed circuit systems, with a nominal pressure of 250 Bar and peak capabilities up to 315 Bar.

• Target Applications: Agricultural machinery, radiator fan drives, small windlasses, industrial HPUs, and municipal vehicle auxiliary drives.

Detailed Model & Parameters:

• Core Series: Rexroth A10FM Series 52.

• Full Model Specification: A10FM63/52R-VWC66N002-S2540.

• Technical Specs Decoding:

  • A10FM63: Size 63, with a displacement of 63 cm³/rev.

  • 52R: Series 52 design; ‘R’ denotes Clockwise rotation.

  • VWC66N002: Indicates specific FKM seals, end-cover porting, and specialized feature options.

  • S2540: Specialized order code referring to specific shaft and flange mounting standards.

• Pressure Specs: Nominal Pressure of 250 Bar (3600 PSI), Peak Pressure reaching 315 Bar.
