Replacement Hydac Industrial Hydraulic Oil Filter Elements

Product Overview:

This series offers premium quality replacements for Hydac filter elements, fully compliant with OEM physical dimensions and filtration efficiency standards. The range includes the D series (Pressure Line) and R series (Return Line). In 2026, these elements are essential for industrial hydraulic maintenance, utilizing high-performance inorganic glass fiber (Betamicron) technology to intercept micron-level contaminants, thereby extending the service life of hydraulic pumps, proportional valves, and actuators.

Featured models: 0030D020BNHC, 0060D003BNHC, 0160D010BNHC, 0240D005BHHC, and 0030R010BNHC.

Key Technical Advantages:

• Premium Media (BN4HC/BH4HC): Features multi-layer composite fiberglass for high dirt-holding capacity and low-pressure drop. BNHC is designed for standard high-pressure use, while BH4HC offers superior collapse resistance against cold starts or pressure spikes.

• Stable Beta Ratings ($\beta_x \ge 200/1000$): Strictly adheres to ISO 16889 standards, ensuring consistent filtration efficiency (e.g., 3μm, 5μm, 10μm, 20μm) throughout the element’s lifespan.

• High Differential Pressure Support: D-series elements utilize high-strength center tubes and end caps, capable of withstanding differential pressures up to 210 bar (BH type) or 20 bar (BN type).

• Wide Chemical Compatibility: Suitable for standard hydraulic oils, water glycols, phosphate esters, and synthetic lubricants. Seals are available in NBR or Viton.

• 100% Interchangeability: Engineered to original mounting standards, ensuring a seamless fit within Hydac filter housings without any plumbing modifications.

Detailed Model Matrix & Parameters:

• High-Pressure D Series:

  • 0030D020BNHC: Size 0030, 20μm rating, standard BNHC collapse resistance.

  • 0060D003BNHC: Size 0060, 3μm rating, ideal for high-sensitivity proportional valve protection.

  • 0160D010BNHC: Size 0160, 10μm rating, general industrial filtration.

  • 0240D005BHHC: Size 0240, 5μm rating, BHHC High-Collapse version.

• Return Line R Series:

  • 0030R010BNHC: Size 0030R, 10μm rating, optimized for return lines.

• Technical Specifications:

  • Filtration Accuracy: 3, 5, 10, 20 micron.

  • Working Medium: Hydraulic oil, lubricating oil, cutting fluids.

  • End Cap Material: Galvanized steel or reinforced engineering plastic.
