Poclain MS08 Series High-Torque Radial Piston Hydraulic Motors

Product Overview: The Poclain MS08 Series is a premier example of global mobile drive technology. As a high-performance High Torque Low Speed (HTLS) radial piston motor, the MS08 is specifically engineered for heavy-load starts and smooth low-speed operation. Its modular architecture allows for direct integration into wheel hubs or shafts, eliminating the need for bulky mechanical gearboxes. This page features precision configurations: MS08-2-12A-R08, MS08-1-1C4-M08, and MS08-6-125-F09. These motors serve as the vital power heart for skid steer loaders, municipal sweepers, orchard tractors, and various medium-duty industrial winch drives.

Key Technical Advantages:

• Elite Torque Response: The radial piston arrangement ensures full torque output even at zero speed, making it ideal for steep-slope starts and complex terrains.

• Versatile Displacement Control:

  • MS08-2 (Dual Displacement): Supports 2-speed switching, allowing vehicles to balance high-torque work modes with high-speed travel.

  • MS08-1 (Single Displacement): Provides constant power delivery for simplified and reliable operations.

• Diverse Interfaces (R08/M08/F09): Offers a wide range of wheel flanges and splined shafts to match global machinery mounting standards.

• Integrated Braking Solutions: Suffixes like 5EGJ/5DEJW denote integrated multi-disc parking brakes, saving chassis space while enhancing safety via hydraulic release mechanisms.

• Target Applications: Wheel loader travel drives, specialized mobile platforms, forestry machinery, industrial mixers, and compact mining equipment.

Detailed Models & Parameters:

• Core Series: Poclain Hydraulics MS08 Series (Radial Piston).

• Technical Specs Decoding:

  • MS08-2-12A-R08-1220-5EGJ: Size 08, 2-speed configuration, R08 wheel interface with 5EGJ integrated braking logic.

  • MS08-1-1C4-M08-1220: Size 08, single (fixed) displacement, 1C4 internal design with M08 shaft end.

  • MS08-6-125-F09-1120-5DEJW: Size 08, reinforced Type-6 housing, F09 flange interface with 5DEJW specialized seals and braking system.

• Performance Indicators:

  • Pressure Rating: Continuous 400 Bar (5800 PSI) / Peak 450 Bar.

  • Displacement Range: Typically covers 467cc to 1248cc.
