Poclain MS08 MSE08 MS11 Motor | MFE08-2-111-A08 | MS11-0-D21-F11 | Radial Piston Wheel Motor

Poclain MS/MSE/MFE/MS11 Series Heavy-Duty Radial Piston Wheel Motors

Product Overview: The Poclain Hydraulics MS/MSE Series is the global gold standard in Low Speed High Torque (LSHT) radial piston technology. Engineered with a modular concept, these motors are specifically optimized for wheel-drive applications in mobile machinery. This selection highlights the high-performance MFE08-2-111-A08-0000-4D00 (optimized for skid steers) and the high-power MS11-0-D21-F11-1110-G000. Renowned for their compact footprint and superior power density, these motors are widely used in agricultural machinery, municipal sweepers, skid steer loaders, port equipment, and construction chassis.

Key Technical Advantages:

• Heavy-Duty Wheel Drive: Designed with oversized bearings that allow direct rim mounting, handling extreme radial and axial loads without the need for additional gearboxes.

• MSE & MFE Compact Optimization: The MSE08/MFE08 series provides a shorter axial length, delivering massive startup torque even in highly restricted installation spaces.

• Integrated Braking Systems: Codes like 1110 or 4D00 denote integrated multi-disc parking or dynamic brakes, ensuring maximum safety during slope operations.

• Multi-Displacement Flexibility: Supports single, twin, or multi-displacement modes, allowing vehicles to adjust traction and travel speed flexibly across different terrains.

• Extreme Durability: Robust cast iron housings and premium seals ensure long service life in muddy, dusty, or extreme temperature environments.

Detailed Models & Parameters:

• Core Series: Poclain MS/MSE/MK/MFE Series.

• Model Keywords: MS08, MSE08, MFE08, MS11, MK Series, MFE08-2-111, MS11-0-D21.

• Technical Specs Decoding:

  • MS08/MSE08: Frame sizes typically covering 1000cc – 1250cc displacements.

  • MS11: Enhanced frame size, with displacements usually ranging from 1250cc to 2100cc/rev.

  • 2-111 / 0-D21: Denotes specific distribution structures and flange interface specifications.

• Pressure Specs: Rated Operating Pressure up to 400 Bar (5800 PSI), with peak capabilities reaching 450 Bar.
