Poclain MS05, MS08, MS11 Series High-Torque Radial Piston Hydraulic Motors

Product Overview: The Poclain MS Series represents the global benchmark in radial piston hydraulic technology, engineered for demanding environments requiring extreme startup torque and smooth low-speed operation. Its unique modular architecture allows for the integration of various brakes, covers, and displacement options. This page highlights key configurations: MS05-2-113-F04, MS08-9-12A-A08, and MS11-0-14A-F12. These motors serve as the vital power source for loader travel drives, agricultural wheel drives, port winches, and industrial shredders.

Key Technical Advantages:

• Elite HTLS Performance: Delivers massive output torque without the need for gear reducers, simplifying drive-line design.

• Robust Radial Load Capacity: Reinforced bearings allow the motor to directly support heavy radial loads at the wheel hub or shaft end.

• Integrated Braking Solutions: Optional multi-disc parking brakes (e.g., 5E/5F sequences) enhance vehicle safety and control.

• Variable Displacement Capability: Supports single or twin displacement options to optimize speed and torque according to the task.

• Target Applications: Wheel loaders, municipal sweepers, harvester wheel drives, heavy-duty hoisting, and forestry machinery.

Detailed Models & Parameters:

• Core Series: Poclain Hydraulics MS Series (MS02/05/08/11).

• Technical Specs Decoding:

  • MS05-2-113-F04-2A50-5EJM: Size 05, ~1130cc displacement class, F04 wheel interface with integrated brake.

  • MS08-9-12A-A08-1120-5DEJM: Size 08, high-torque configuration, A08 shaft standard.

  • MS11-0-14A-F12-2A11-5FHM0: Size 11, F12 heavy-duty flange, equipped with high-performance braking logic.

• Performance Specs: Rated continuous operating pressure up to 400 Bar – 450 Bar.
