Parker TG Series Motor | TG405 TG475 TG530 TG625 TG785 TG960 | TG530MS030AAAB
| Model Number | TG530MS030AAAB |
|---|
Product Description
Parker TG Series Heavy-Duty LSHT Hydraulic Orbit Motors
Product Overview: The Parker TG Series is an elite range of disc-valve orbital hydraulic motors engineered for the most extreme and demanding operating environments. This product category features the full displacement spectrum: TG405, TG475, TG530, TG625, TG785, and TG960, with a specialized focus on model TG530MS030AAAB.
Utilizing Parker’s patented Roller Vane technology, TG Series motors minimize internal friction and elevate mechanical efficiency through roller-supported stator vanes. Its defining characteristic is the oversized Tapered Roller Bearing set, allowing the motor to directly sustain massive radial and axial loads. These are the premier power units for construction propel drives, heavy-duty winches, forestry harvesters, and sweeper brush systems.
Key Technical Advantages:
Superior Load Resilience: Integrated heavy-duty tapered roller bearings handle extreme side-loading, enabling direct wheel or gear drive without auxiliary bearing supports.
Roller Vane Efficiency: Compared to standard gerotors, the roller design ensures lower breakout pressure and smoother low-speed operation, significantly extending service life.
Rugged Sealing Technology: High-pressure shaft seals manage system back-pressure spikes with ease, reducing the necessity for external case drains in most systems.
Technical Decoding:
TG530MS030AAAB: The “MS” denotes the standard mounting configuration, while “030” specifies exact shaft and porting dimensions for a guaranteed 100% OEM fit.
Detailed Specifications & Parameters:
Core Series: Parker Hannifin TG Series (Standard & Wheel Mount)
Featured Model Matrix: TG530MS030AAAB, TG405, TG475, TG530, TG625, TG785, TG960
Core Performance Specs:
Displacement Range: 140 cc/rev to 960 cc/rev (8.6 – 58.5 cu in/rev)
Rated Pressure: Continuous up to 200 Bar (2900 PSI); Intermittent peaks exceeding 300 Bar (4350 PSI)
Torque Capability: Continuous torque up to 1250 Nm, with intermittent peaks reaching 1490 Nm
Mounting Standards: SAE A 2-Bolt, 4-Bolt Square, and Wheel Mount flanges
Shaft Options: 1-1/4″ Keyed, Splined, or Tapered shaft options available
