Parker TF0240 TF0360 Motor | TF0360AB050AAAB | TF0240AB050AAAB | TF0130 TF0280

Parker TF Series Heavy-Duty LSHT Hydraulic Orbit Motors

Product Overview: The Parker TF Series Torqmotor™ is synonymous with high performance and reliability in hydrostatic drive systems. Engineered with advanced Geroler technology, the TF series is specifically designed for medium-to-heavy-duty applications, delivering smooth and massive torque at low speeds. This page features precision-configured models: TF0360AB050AAAB and TF0240AB050AAAB, while covering core displacements TF0130 and TF0280. Renowned for their elite side-load capacity, these motors are the premier choice for conveyor drives, sweeper brushes, winch systems, heavy-duty agricultural machinery, and construction equipment.

Key Technical Advantages:

• Elite Side-Load Capacity: Features oversized, heavy-duty tapered roller bearings designed to handle significant radial forces from chain, gear, or belt drives directly, eliminating the need for external supports.

• Geroler Technology: The roller-vane rotor design minimizes internal friction, ensuring exceptionally smooth operation at ultra-low speeds and maximum startup torque across the range.

• High-Pressure Shaft Seal: Equipped with high-capacity seals that withstand substantial back pressure (up to 200 Bar), simplifying hydraulic plumbing by eliminating the need for a case drain in most systems.

• Robust Construction: High-strength cast iron housings are engineered to endure frequent shock loads and extreme operating environments.

• Target Applications: Industrial augers, sweeper main brush drives, marine winches, forestry attachments, and specialized chassis propulsion.

Detailed Models & Parameters:

• Core Series: Parker Hannifin Torqmotor™ TF Series.

• Model Keywords: TF0130, TF0240, TF0280, TF0360, TF0360AB, TF0240AB.

• Technical Specs Decoding:

  • TF0240: Approx. 240cc/rev (14.5 in³/rev) displacement, optimized for a perfect balance between speed and torque efficiency.

  • TF0360: Approx. 360cc/rev (22.2 in³/rev) displacement, providing enhanced startup traction and low-speed stability.

  • AB050: Denotes specific shaft configurations (e.g., 1-1/4″ Keyed or Splined shaft) and precision porting options.

• Pressure Specs: Continuous operating pressure up to 140 Bar (2000 PSI), with peak capabilities reaching 200 Bar (3000 PSI).
