Parker TE0165 TE0295 Motor | TE0165CW690AAAB | TE0295AS100AAAA | LSHT Hydraulic Motor

Parker TE Series Low Speed High Torque (LSHT) Hydraulic Motors

Product Overview: The Parker TE Series Torqmotor™ stands as a benchmark for reliability in industrial drives and mobile machinery. Engineered as a high-performance Low Speed High Torque (LSHT) orbital motor, the TE series is specifically designed for applications requiring smooth torque output and superior side-load capacity. This page features precision-configured models: the standard heavy-duty TE0295AS100AAAA and the specialized TE0165CW690AAAB. Utilizing advanced geroler technology, these motors excel in conveyor drives, sweeper brushes, winch systems, agricultural attachments, and material handling equipment.

Key Technical Advantages:

• Superior Side-Load Capacity: Engineered with robust internal bearings to handle significant radial forces from chain or gear drives directly, eliminating the need for external bearing supports.

• Advanced Geroler Technology: The roller-vane rotor design minimizes internal friction, ensuring maximum torque at startup and exceptionally smooth operation at ultra-low speeds.

• High-Pressure Shaft Seal: Equipped with high-capacity seals that withstand substantial back pressure, simplifying hydraulic plumbing by eliminating the need for a case drain in most systems.

• Extreme Compactness: Delivers massive output power within a minimal footprint, ideal for integration into wheel drives or sweeping mechanisms of compact mobile machinery.

• Target Applications: Industrial conveyor belts, sweeper brush rotation, compact winch drives, agricultural seeders, and food processing propulsion.

Detailed Models & Parameters:

• Core Series: Parker Hannifin Torqmotor™ TE Series.

• Model Keywords: TE0165, TE0295, TE0165CW690, TE0295AS100.

• Technical Specs Decoding:

  • TE0165 Series: Approx. 165cc/rev (10.1 in³/rev) displacement, optimized for balanced efficiency and high-speed performance.

  • TE0295 Series: Approx. 295cc/rev (18.0 in³/rev) large displacement, providing massive startup torque and load-pulling power.

  • CW690 / AS100: Denotes specific shaft configurations (e.g., 1-inch 6B Spline, Keyed, or Tapered shafts) and mounting flange standards (e.g., SAE A 2-bolt).

• Pressure Specs: Continuous operating pressure up to 140 Bar (2000 PSI), with peak capabilities reaching 175 Bar.
