Parker TE0036 & TE0365 High-Performance LSHT Hydraulic Motors

Product Overview: The Parker TE Series (formerly Torqmotor™) is a benchmark for efficiency and robustness in the hydrostatic drive industry. Engineered with advanced Geroler technology, the TE series is specifically designed for applications requiring high startup torque within a restricted axial footprint. This page highlights two precision-configured models: the ultra-compact TE0036CW410LAAY and the high-torque powerhouse TE0365DW260AAAB. Renowned for their high-strength cast iron housings, these motors are the premier choice for conveyor drives, sweeper brush rotation, precision rotators, agricultural seeder attachments, and food processing equipment.

Key Technical Advantages:

• Superior Side-Load Capacity: Features an integrated heavy-duty bearing system that handles radial forces from chain or gear drives directly, eliminating the need for external supports and reducing assembly costs.

• Geroler Technology: The roller-vane rotor design minimizes internal friction, ensuring exceptionally smooth operation at ultra-low speeds (even below 1 RPM) and maximum mechanical efficiency.

• High-Pressure Shaft Seal: Equipped with high-capacity seals that withstand significant back pressure, simplifying hydraulic plumbing by eliminating the need for a case drain in most systems.

• LAAY Advanced Configuration: Models like the TE0036CW410LAAY include specialized seals or valving enhancements for extended service life in high-dust environments or frequent reversal cycles.

• Target Applications: Compact industrial winches, sweeper attachments, woodworking machinery, automated production lines, and material handling systems.

Detailed Models & Parameters:

• Core Series: Parker Hannifin Torqmotor™ TE Series.

• Model Keywords: TE0036, TE0365, TE0036CW410, TE0365DW260.

• Technical Specs Decoding:

  • TE0036 Series: Approx. 36cc/rev (2.2 in³/rev) displacement, optimized for high speed and miniaturized drive requirements.

  • TE0365 Series: Approx. 365cc/rev (22.2 in³/rev) displacement, delivering the maximum torque output and pulling power within the series.

  • CW410 / DW260: Denotes specific shaft configurations (e.g., 1-inch 6B Spline or 1-inch Keyed shaft) and standard mounting flange options.

• Pressure Specs: Continuous operating pressure up to 140 Bar (2000 PSI), with peak capabilities reaching 190 Bar.
