Parker TE0050 TE0065 Motor | TE0050CW260LAAY | TE0065US110ABBA | LSHT Hydraulic Motor
| Model Number | TE0065US110ABBA, TE0050CW260LAAY |
|---|
Product Description
Parker TE0050 & TE0065 Compact LSHT Hydraulic Motors
Product Overview: The Parker TE Series (formerly Torqmotor™) is a benchmark in high-performance Low Speed High Torque (LSHT) propulsion. This series is specifically engineered for industrial and mobile applications requiring a small footprint combined with elite side-load capacity. This page features precision configurations: the specialized TE0050CW260LAAY and the industry-standard TE0065US110ABBA. Utilizing advanced orbital technology, these motors excel in small conveyor drives, sweeper brushes, textile machinery, agricultural seeder attachments, and food processing equipment.
Key Technical Advantages:
Superior Side-Load Capacity: The TE series integrates heavy-duty bearings within its compact housing, allowing it to handle radial forces from chain or gear drives directly without external supports.
Geroler Technology: The roller-vane design minimizes internal friction, ensuring maximum torque at startup and exceptionally smooth operation at ultra-low speeds.
High-Pressure Shaft Seal: Equipped with high-capacity seals that withstand substantial back pressure, simplifying hydraulic plumbing by eliminating the need for a case drain in most systems.
Extreme Compactness: Its minimal axial length allows for easy installation into space-restricted wheel hubs or machine enclosures, maximizing design flexibility.
Target Applications: Agricultural seeders, food processing lines, compact winches, industrial rotators, and sweeper attachment drives.
Detailed Models & Parameters:
Core Series: Parker Hannifin Torqmotor™ TE Series.
Model Keywords: TE0050, TE0065, TE0050CW260, TE0065US110.
Technical Specs Decoding:
TE0050: Approx. 50cc/rev (3.0 in³/rev) displacement, optimized for higher speeds and lightweight drive requirements.
TE0065: Approx. 65cc/rev (4.0 in³/rev) displacement, providing enhanced torque output within a compact envelope.
CW260 / US110: Denotes specific shaft configurations (e.g., 1-inch 6B Spline, Keyed shaft) and mounting flange standards (e.g., SAE A 2-bolt or 4-bolt).
Pressure Specs: Continuous operating pressure up to 140 Bar (2000 PSI), with peak capabilities reaching 190 Bar.
