Parker PV29 EH Oil Pump | PV29-2R5D-C00 | Steam Turbine Control System | Fire-Resistant Fluid Piston Pump
| Flow Rate | Customizable |
|---|
Product Description
Parker PV29-2R5D-C00 Steam Turbine EH Oil System Piston Pumps
Product Overview: The Parker PV29-2R5D-C00 is a heavy-duty axial piston variable pump specifically engineered for the power generation industry. It is extensively utilized in High-Pressure Fire-Resistant Oil (EH Oil) actuator and governing systems for large-scale steam turbines. As a core model of the PV Series, the PV29 offers a displacement of 29 cm³/rev and features full compatibility optimization for fire-resistant fluids (e.g., Fyrquel) through specialized seals and materials. Renowned for its “High-Pressure Stability” and “Extended Service Life,” this pump ensures the turbine’s DEH control system responds precisely to valve commands under continuous duty cycles.
Key Technical Advantages:
Fluid-Specific Seals: Equipped with specialized Viton (FKM) or compatible seals designed to resist phosphate ester fluid corrosion, preventing internal leakage and shaft seal failure.
Fast Dynamic Response (C00): The integrated pressure compensator modulates flow instantaneously based on system demand, keeping EH oil pressure stable at setpoints (typically around 14 MPa).
Low Noise & Vibration Suppression: Optimized valve plate decompression significantly suppresses pressure ripples, reducing operational noise and vibration impact on control piping.
Heavy-Duty Long-Life Build: Built with oversized bearings and reinforced piston groups, ensuring low failure rates in 24/7 power plant environments.
100% Turbine OEM Compatibility: Adheres strictly to industrial mounting standards (Series 20 design), ensuring flanges and shaft extensions align perfectly with original EH Hydraulic Power Units (HPU).
Detailed Models & Parameters:
Core Series: Parker PV Series (Size 29).
Full Model: PV29-2R5D-C00.
Displacement: 29 cm³/rev (1.77 in³/rev).
Pressure Ratings: Rated at 350 Bar (5000 PSI) continuous; designed for high-cycle fatigue resistance.
Rotation: 2R (Clockwise/CW).
Target Applications: Steam turbine EH oil stations, DEH control system actuators, and power generation governing units.
Purchase need
1.The company brand model series is complete, many do not have one by one you need what type of product, please contact customer service.
2.We hope that our products is your right product, we are responsible for you is also responsible for our own, and every cooperation is the source of our company’s life.
Product Features:
1. Axial piston pump with swashplate design for hydraulic drive in open circuit
2. Optional installation location
3. Excellent oil absorption characteristics
4. Low noise level
5. Long service life
6. Modular design
7. Short response time
8. Variable speed drive options
9. Visible swing angle indicator
10. The flow rate is proportional to the input transmission speed and displacement. By adjusting the swashplate angle, the output flow can be steplessly adjusted.
11. Use of HF oil in the case of reduced operating data There is a special model that can be used to run with HFC oil
