Parker PV063 Series Pump | PV063R1K4T1NMMC, PV063R1K1A1NFHS | 350 Bar Piston Pump

Parker PV063 Series High-Pressure Industrial Variable Piston Pump

Product Overview: The Parker PV Series is a globally recognized premium power source for industrial hydraulic systems. The PV063 model, with a displacement of 63 cm³/rev, is engineered for demanding industrial environments requiring high precision and extended service life. Rated for a continuous operating pressure of 350 Bar, flagship models such as the PV063R1K4T1NMMC and PV063R1K1A1NFHS feature unique “breathing” compensator designs and acoustic housing. These innovations deliver ultra-fast dynamic response and industry-leading low noise levels, making them the ideal choice for automated production lines and heavy-duty industrial machinery.

Key Technical Advantages:

• Exceptional Pressure Performance: Rated at 350 Bar (35 MPa) with peak capabilities up to 420 Bar. Reinforced rotating groups and oversized bearings ensure maximum reliability under continuous heavy-duty cycles.

• Rapid Dynamic Response: Optimized compensator structures guarantee ultra-short response times during pressure transitions, significantly improving system cycle efficiency.

• Versatile Control Options:

  • K1/K4 Pressure Compensators: Automatically adjust displacement to maintain preset pressure.

  • A1 Load Sensing: Delivers only the exact flow and pressure required by the load, drastically reducing energy waste.

  • X5899 Special Modification: Suffix codes representing tailored optimizations for specific high-heat or specialized fluid applications.

• Ultra-Quiet Technology: Utilizing pre-compression volume technology, the pump minimizes fluid pulsations and mechanical vibrations, achieving superior noise reduction.

• Universal Configurations (FHS/FFP): Offers multiple flange, shaft (Keyed or Splined), and porting options to ensure seamless compatibility with existing equipment globally.

Detailed Models & Parameters:

• Core Series: Parker PV Series.

• Representative Models: PV063R1K4T1NMMC, PV063R1K1A1NFHS, PV063R1R1T1NMMCX5899, PV063R1K1T1NFFP.

• Displacement: 63 cm³/rev.

• Pressure Ratings: Rated at 350 Bar (5000 PSI); Peak cycles up to 420 Bar (6000 PSI).

• Rotation: R (Clockwise / Right-hand rotation).
