Parker Full Series LSHT Hydraulic Orbit Motors (TB, TE, TF, TG, TK)

Product Overview: Parker (Parker Hannifin) orbital hydraulic motors are globally recognized for their superior durability and precision engineering in Low Speed High Torque (LSHT) applications. This category features the full spectrum of Parker’s lineup, ranging from the cost-effective and compact TB/TE Series to the mid-to-heavy duty benchmarks TF/TG Series, and the powerhouse TK Series.

Featured precision configurations include: TB0390AP100AAAA, TE0080CW260LABA, and TE0295CW250BBCP. Whether used in high-cycle industrial production lines or harsh mobile environments like wheel drives and sweepers, Parker motors utilize advanced roller vane technology to deliver consistent, robust power output.

Core Series Technical Breakdown:

• TB/TE Series: Compact spool valve design. These motors offer high power density and optimized bearing designs to provide high torque in a minimal footprint, ideal for conveyors and auxiliary drives.

• TF/TG Series: Mid-to-heavy duty disc valve motors. The TG Series, as an industry standard, is renowned for its heavy-duty bearing layout and exceptional side-load resilience.

• TK Series: The “Power King” of the Parker family. Engineered for extreme pressures and ultra-high torque demands, commonly found in forestry, mining, and large construction machinery.

Detailed Specifications & Parameters:

• Core Series: Parker Hannifin TB, TE, TF, TG, TK Series.

• Featured Model Matrix: TB0390AP100AAAA, TE0080CW260LABA, TE0295CW250BBCP.

• Core Performance Specs:

  • Displacement Range: 36 cc/rev to 1000 cc/rev (2.2 – 61.0 cu in/rev).

  • Rated Pressure: Continuous up to 200 Bar (2900 PSI); Intermittent peaks exceeding 300 Bar (4350 PSI).

  • Torque Capability: Spanning from 50 Nm to 2300 Nm (model dependent).

  • Shaft Options: 1″ Keyed, 1-1/4″ Keyed, Splined, and Tapered options available.

  • Mounting Standards: SAE A 2-Bolt, 4-Bolt Square, and Magneto 2-Bolt flanges.
