Parker F12 Motor | F12-040, F12-060, F12-080, F12-110 | Bent-Axis Piston Motor

Parker F12 Series High-Performance Bent-Axis Piston Motors

Product Overview: The Parker F12 Series is a premium bent-axis, fixed displacement piston motor engineered for the most demanding operating conditions. Featuring a unique 40° bent-axis design, the F12 series combines a compact envelope with outstanding reliability at high speeds and extreme pressures. This featured selection includes core configurations: from the versatile F12-040 and F12-060 to the robust F12-080 and F12-110. With multiple shaft options (including D-Keyed, K-Splined, and S/T specialized shafts), the F12 series operates at peak pressures up to 480 Bar, making it the definitive choice for saw drives, winches, mowing equipment, and high-performance fan drives.

Key Technical Advantages:

• Superior Speed Capability: Precision-balanced rotating groups allow for exceptionally high-speed operation, ideal for drive systems requiring rapid response.

• Extreme Pressure Resilience: Rated for 420 Bar (6100 PSI) continuous and 480 Bar (7000 PSI) peak pressure, engineered to handle severe pressure spikes.

• High Mechanical Efficiency: The 40° bent-axis angle minimizes friction loss, significantly increasing power density while reducing heat generation.

• Flexible Mounting & Sealing: Available in MF/MS mounting flanges with various shaft specifications (D, K, S, T) to ensure compatibility with global OEM equipment.

• Target Applications: Timber harvesting saw drives, high-speed fan systems, construction machinery winches, agricultural implement drives, and closed-circuit systems.

Detailed Models & Parameters:

• Core Series: Parker F12 Series (Bent-Axis Design).

• Model Keywords: F12-040, F12-060, F12-080, F12-110, MF-IV-D, MS-SV-T.

• Technical Specs Decoding:

  • F12-080/060/040-MF-IV-D: Features D-type keyed shaft and MF standard flange for direct coupling.

  • F12-040-MF-IV-K: Equipped with K-type splined shaft for enhanced stability under high torque.

  • F12-060/110-MS-SV-T / F12-110-MS-SV-S: MS flange series with SV premium sealing and S/T specialized shafts for customized heavy-duty drives.

• Pressure Specs: Rated operating pressure 420 Bar, Peak pressure 480 Bar.

• Displacement Range: Offering a versatile spectrum from 40 cm³/rev up to 110 cm³/rev.
