Oilgear PVG Series Pump | PVG-100, PVG-150 | 350 Bar Axial Piston Pump

Oilgear PVG Series High-Performance Axial Piston Variable Pump

Product Overview: The Oilgear PVG series axial piston variable pumps are globally recognized for their exceptional durability and precision control in extreme industrial environments. Covering core displacements such as 100cc (PVG-100) and 150cc (PVG-150), this series supports a rated operating pressure of up to 350 Bar. PVG pumps feature a unique hydrostatically balanced design and robust bearing systems, enabling them to handle low-viscosity fluids while providing an extended service life. Whether equipped with load-sensing or pressure compensation controls, the PVG series delivers incredibly stable power for forging, extrusion, and heavy-duty injection molding machinery.

Key Technical Advantages:

• Heavy-Duty High-Pressure Performance: Engineered for continuous heavy-duty load cycles. Supports a rated operating pressure of 350 Bar (5000 PSI) with peak cycles up to 400 Bar (5800 PSI). The reinforced structure ensures peak volumetric efficiency under grueling conditions.

• Sophisticated Precision Controls (LGFY/LDFY): * Model PVG-150-A1UV-LGFY integrates advanced compensation logic, allowing for rapid displacement adjustments based on system demand, significantly reducing energy loss.

  • The LDFY and LGFY control options ensure rapid response times and stability under dynamic loads, facilitating precise flow management.

• Superior Fluid Compatibility: The PVG series is capable of operating with a wide range of special hydraulic fluids, including low-viscosity types, offering an irreplaceable advantage in chemical and specialized heavy industrial sectors.

• Low Noise & Compact Envelope: Optimized flow paths and a rigid housing design not only dampen operational noise but also minimize the installation footprint, allowing for easy integration into modern compact Hydraulic Power Units (HPU).

Detailed Models & Parameters:

• Core Series: Oilgear PVG Series.

• Detailed Config Codes: PVG-150-A1UV-LGFY-P-J3SSN-088498, PVG-100-F1UV-LDFY-P-1NNSN-CN.

• Displacements: 100 cm³/rev (PVG-100), 150 cm³/rev (PVG-150).

• Pressure Ratings: Rated at 350 Bar (5000 PSI); Peak cycles up to 400 Bar (5800 PSI).

• Materials & Seals: Constructed with high-strength alloy components and specialized seal options to ensure zero-leakage operation under high pressure.
