Northman Type DSV Valve | DSV-G02-6C DSV-G03-2A DSV-G03-2AL | NG6 NG10 Directional Valve
| Model Number | DSV-G02-2N-DC24-20, DSV-G02-6C-DC24-90, DSV-G03-2A-A110-82-A, DSV-G03-2AL-A110-82-A |
|---|
Product Description
Northman Type DSV-G02/G03 Series Solenoid Directional Control Valves
Product Overview: The Northman DSV Series represents a premium range of direct-operated solenoid directional valves, recognized for their high durability and switching precision in industrial hydraulic systems. Fully compliant with ISO 4401 mounting standards, this series is available in Size 02 (NG6 / CETOP 03) and Size 03 (NG10 / CETOP 05) footprints. The wet-pin solenoid design ensures quiet operation and an extended mechanical service life, even under high-frequency switching cycles.
This selection features essential configurations: the 2-position single solenoid spring-offset DSV-G03-2A and DSV-G03-2AL (with left-hand offset characteristics), along with the 3-position specialized logic DSV-G02-6C. Optimized for global industrial power standards including DC24V and AC110V.
Key Technical Advantages:
Superior Switching Stability: Precision-ground spools paired with robust solenoids ensure accurate, zero-lag position switching even under high-pressure and high-flow conditions.
Wet-Pin Solenoid Architecture: Armatures operate fully immersed in hydraulic oil, providing superior self-lubrication and shock absorption while significantly reducing operational noise.
Low Pressure-Drop Flow Paths: Internal galleries are fluid-dynamically optimized to minimize energy loss and enhance overall hydraulic system efficiency.
High Ingress Protection: Features high-grade coils with excellent insulation and dust/water resistance, suitable for harsh industrial manufacturing environments.
Detailed Specifications & Parameters:
Core Series: Northman Type DSV Series.
Featured Model Matrix: DSV-G03-2A-A110-82-A, DSV-G03-2AL-A110-82-A, DSV-G02-6C-DC24-90.
Core Performance Specs:
Nominal Sizes: G02 (Size 02 / NG6) and G03 (Size 03 / NG10).
Max Operating Pressure: Rated up to 25-31.5 MPa (250-315 Bar / 4,500 PSI).
Max Flow Capacity: G02 up to 80 L/min; G03 up to 160 L/min.
Voltage Specs: A110 (AC110V 50/60Hz); DC24 (24V DC).
Spool Functions: 2A (2-pos single solenoid); 2AL (Left-hand solenoid); 6C (3-pos Tandem center).
Design Sequences: 82 Series, 90 Series.
DSV-G026CDC24-90
DSV G 036C DC24-82
DSV-G-03-2C-DC24-82
DSV G 036C DC24-82
DSV-G-03-2C-DC24-82
DSV-G02-2AL-A110-20T
DSV-G02-2N-A110-20T
DSV-G02-2N-A110-20T
DSV-G02-6C-DC24-90
DSV-G03-6C-D24-82
DSV-G03-6C-D24-82
