Nachi Type SS Series Solenoid Valve | SS-G01 | SS-G03-H3Z-FR | SS-G03-C6S | Wet Type Directional Control

SS Series Wet Type Solenoid Operated Directional Control Valves

Product Overview: The SS series represents a premier line of wet-type solenoid directional valves, renowned for exceptional reliability, long operational life, and ultra-low power consumption. By utilizing a wet-armature design where the plunger is immersed in system oil, this series eliminates oil leakage at the pushrod and achieves whisper-quiet switching via fluid cushioning. From the compact SS-G01 (NG6) to the high-capacity SS-G03 (NG10), these valves provide stable control performance even under severe, high-frequency industrial environments.

Featured models: SS-G03-H3Z-FR-E115-E22 and SS-G03-C6S-R-C2-J22.

Key Technical Advantages:

• Extended Life & Quiet Operation: The wet-solenoid design drastically reduces mechanical wear and provides smooth, low-noise switching, significantly outlasting dry-type solenoids.

• Energy-Efficient Design: Optimized coil architecture reduces operating current, lowering energy consumption and minimizing system heat generation.

• High Pressure & Flow Capacity: The G03 size handles pressures up to 35 MPa, making it ideal for heavy-duty industrial machinery.

• Global Voltage Compatibility: Available in various voltage ratings such as E115 (AC 115V) and J22 (AC 200/220V), with flexible terminal box configurations.

Detailed Specifications & Parameters:

• Featured Model Matrix:

  • SS-G03-H3Z-FR-E115-E22: Size 10, H3Z spool function, FR specific flow/response characteristic, AC 115V supply.

  • SS-G03-C6S-R-C2-J22: Size 10, C6S specific spool (e.g., tandem center), R with indicator light, AC 200V/220V supply.

• Core Technical Specs:

  • Nominal Size: Size 01 (NG6) / Size 03 (NG10).

  • Max Operating Pressure: 35 MPa (5076 PSI).

  • Max Flow Rate: Up to 100 L/min (G01) / 160 L/min (G03).

  • Enclosure Rating: IP65 (with standard terminal box).

  • Switching Frequency: Supports up to 300 cycles per minute.
