Linde M6 Series Motor | M6V1N1C2A0A00, M6V3N1C2A0A00 | High Pressure Fixed Displacement Motor

Linde M6 Series High-Pressure Fixed Displacement Hydraulic Motors

Product Overview: The Linde M6 Series represents the pinnacle of power components for hydrostatic transmission systems in extreme operating conditions. As a high-pressure swashplate fixed displacement motor, the M6 series is renowned for its ultra-high power density and exceptional low-speed stability. This featured selection includes core industrial configurations: M6V1N1C2A0A00, M6V3N1C2A0A00, and the full M6G/M6F series. With transient pressure capabilities up to 500 Bar, the M6 series is the premier choice for heavy excavator travel drives, agricultural harvester power shafts, large rotary drilling rigs, crane winches, and demanding industrial mixing systems.

Key Technical Advantages:

• Peak Pressure Resilience: Rated for continuous operation at 450 Bar with peak capabilities up to 500 Bar (7250 PSI), making it one of the most robust motors on the market.

• High Volumetric Efficiency: Optimized valve plate design and low-friction piston technology ensure maximum efficiency and minimal energy loss across the entire speed range.

• Exceptional Low-Speed Smoothness: The unique swashplate layout eliminates “creeping” at low speeds, providing smooth and consistent starting torque.

• Rugged Engineering: Reinforced housing and high-capacity bearing systems are optimized for continuous heavy-duty cycles and high-frequency shock loads, significantly extending service intervals.

• Compact Modular Configuration: Different port and mounting styles in M6V / M6F provide superior integration flexibility for direct mounting on wheel drives or industrial gearboxes.

• Target Applications: Crawler travel propulsion, heavy-duty crane winch drives, oil drilling equipment, forestry machinery, and closed-circuit hydrostatic transmissions.

Detailed Models & Parameters:

• Core Series: Linde M6 Series (M6V, M6G, M6F).

• Model Keywords: M6V1N1C2A0A00, M6V3N1C2A0A00, M6F, M6G.

• Technical Specs Decoding:

  • M6V1 / M6V3: Refers to specific displacement sizes and design iterations.

  • N1C2A: Refers to drive shaft splines, mounting flange standards, and port configurations.

  • 0A00: Denotes specialized sealing and application-specific parameters.

• Pressure Specs: Nominal Pressure 450 Bar, Peak Pressure 500 Bar (7250 PSI).
